LP12 Cable to Cable Connector
2. Available in IP67 and IP68 waterproof ratings for reliable performance in wet environments.
3. Solder-type termination provides secure and durable wire-to-wire connections.
4. Snap-lock bayonet coupling allows one-handed plug and unplug operation.
5. Rated for -40℃ to +105℃ operating temperature with UL94-V0 flame retardant housing.
6. Tested for 2000+ mating cycles for long-term reliability in demanding applications.
7. TUV and CE certified, manufactured under ISO9001 quality management.
8. Custom options include pin count (2-8 pins), housing material (plastic/metal), and cable length.
LP12 Cable to Cable Connector – Industrial Waterproof Inline Connector Solution
The LP12 Cable to Cable Connector from Cablein Technology is an enterprise-grade circular inline connector engineered for high-density, space-critical applications. With a compact 12mm mounting diameter, it delivers IP67/IP68 waterproof protection and features a snap-lock bayonet mechanism tested for 2000+ mating cycles. Built with PA66 nylon housing and gold-plated copper alloy contacts, it supports 2–8 pin configurations with rated current up to 5A and voltage up to 125V. Operating reliably from -40℃ to +105℃, this product enables secure wire-to-wire connections in LED lighting, industrial automation, and outdoor electronics—eliminating signal loss and moisture ingress in demanding field conditions.
Key Properties and Technical Specifications
Understanding the specialized spine of this connector makes a difference you make educated choices for your projects.
Premium Fabric Construction
Your connector highlights gold-plated copper amalgam contacts. These keep up contact resistance underneath 10mΩ for steady flag and control transmission. The PA66 or PBT lodging offers UL94-V0 fire retardancy. It stands up to oils, solvents, and UV presentation. This makes it perfect for both indoor and open air deployments.
Reliable Fixing and Protection
You get IP68-rated waterproof execution with silicone fixing rings. The connector anticipates clean entrance and withstands transitory submersion. This guarantees your gear works dependably indeed in damp or dusty environments.
Flexible Stick Configuration
Choose from 2 to 8 pins based on your application needs. The appraised wire segment ranges from 0.34 to 0.5mm². Cable breadth compatibility ranges Φ3–Φ6mm. This adaptability bolsters both control and flag transmission in compact layouts.
Wide Temperature Tolerance
Your connector works from -40℃ to +105℃. A few variations handle up to 180℃. This temperature extend suits extraordinary climates and high-heat mechanical environments.
Application Scenarios for LP12 Cable Connectors
This LP12 Cable to Cable Connector solves real-world connectivity challenges across multiple industries.
Outdoor Driven and Keen Lighting
You require measured associations for Driven strips, drivers, and controllers. The LP12 cable-to-cable plan permits simple field establishment without board mounting. Its waterproof rating secures against rain and stickiness. You keep up brightness and control flag astuteness in structural and scene lighting projects.
Industrial Computerization and Robotics
Your mechanical arms and transport frameworks require vibration-resistant associations. The snap-lock component anticipates inadvertent disengagement amid high-speed development. Sensor cables and actuator wiring remain secure. You decrease downtime and progress framework reliability.
Marine and UAV Electronics
Weight and space are basic in rambles and marine route gear. The compact LP12 connector joins control leads to flight controllers and sensors. It withstands saline environments and tall stickiness. You accomplish tried and true network in requesting portable platforms.
Solar Vitality and EV Systems
Your renewable vitality establishments require tough wire-to-wire associations. The connector's temperature resistance and waterproof execution suit open air sun oriented boards and EV charging framework. You guarantee long-term electrical judgment with negligible maintenance.
Core Advantages of Cablein's LP12 Solution
One-Handed Snap-Lock Design
Push-pull pike coupling permits fast mating and unmating. You listen an capable of being heard press affirming secure engagement. This speeds up establishment and diminishes labor costs in the field.
Long Mechanical Life
Tested for over 2000 mating cycles, your connector keeps up execution over a long time of utilize. This diminishes substitution recurrence and add up to fetched of ownership.
International Compliance
TUV and CE certified beneath ISO9001 quality administration. You meet worldwide security and natural benchmarks. This streamlines advertise section and administrative compliance.
Custom Flexibility
Cablein offers OEM/ODM administrations. You can indicate stick number, lodging fabric (plastic or metal), cable length, and conductor gage. Our designing group bolsters private form improvement for specialized projects.
Frequently Asked Questions
Q1: What is the most extreme voltage rating for the product?
A: It bolsters 125V for 2–4 stick forms and 100V for 5–8 stick setups, tried to IEC measures for dependable operation in control and flag applications.
Q2: Can the connector be utilized underwater?
A: Yes, when legitimately collected with the redress cable breadth and fixed organs, it accomplishes IP68 rating reasonable for brief submersion up to 1 meter.
Q3: How does the snap-lock perform in high-vibration environments?
A: The locking component meets MIL-STD-202G vibration benchmarks, guaranteeing the association remains secure indeed beneath steady mechanical stretch in mechanical and portable equipment.
Q4: Is it consistent with distinctive cable diameters?
A: The inner fixing ring and cable organ oblige cable external breadths from Φ3mm to Φ6mm, giving a watertight fit over different cable types.
Q5: What end strategy does the LP12 use?
A: Solder-type end gives tough and dependable associations. This strategy guarantees moo contact resistance and long-term soundness in requesting applications.
Q6: Does Cablein offer pre-assembled cable assemblies?
A: Yes, we give custom cable saddle arrangements with pre-soldered LP12 connectors, indicated cable lengths, and conductor gages custom fitted to your venture requirements.
Quality Assurance and Testing
Every LP12 connector undergoes comprehensive quality control protocols.
You benefit from contact resistance testing per IEC 60512-2-1. Insulation resistance and dielectric withstanding voltage tests prevent short circuits. Salt spray testing (48–72 hours) verifies corrosion resistance. IP68 submersion testing validates seal integrity. Mechanical pull-out force testing ensures cable strain relief withstands field tension.
These rigorous checks guarantee zero-failure performance in mission-critical applications.
Why Choose Cablein Technology?
Since 2017, Cablein has specialized in industrial waterproof connectors. Our 6,000㎡ facility in Shenzhen houses advanced production equipment. A team of over 200 professionals ensures stable quality and fast delivery.
We maintain inventory of 10,000+ pieces per item. Standard orders ship in 7–10 days. You get efficient global logistics through UPS, DHL, and FedEx partnerships.
Our 30+ utility model patents reflect continuous innovation. We support you with 24-hour technical assistance and end-to-end project consulting.
Ready to Connect with Confidence?
Discover how the LP12 Cable to Cable Connector can enhance your product reliability. Contact us at nick@cableinco.com to request technical specifications, confirm compatibility, or discuss sample availability for your project.
