LP16 Flange Mount Connector
2. Offers IP67 and IP68 waterproof protection for bulkhead installation.
3. Solder-type termination provides reliable wire attachment for internal connections.
4. Four-hole flange mounting ensures secure attachment to equipment enclosures.
5. Rated for -40℃ to +105℃ operating temperature with UL94-V0 flame retardant housing.
6. Tested for 2000+ mating cycles for long-term durability.
7. CE and RoHS certified, manufactured under ISO9001 quality control.
8. Custom pin count, housing material, and flange configuration available.
LP16 Flange Mount Connector: Enterprise-Grade Waterproof Panel Solutions
The LP16 Flange Mount Connector is a precision-engineered industrial circular connector featuring a 16mm mounting diameter and a robust four-hole square flange design. Built with PA66 nylon lodging and gold-plated copper amalgam contacts, it conveys IP67/IP68 waterproof security for requesting bulkhead establishments. This connector bolsters 2-9 stick arrangements, works dependably from -40℃ to +105℃, and is tried for over 2000 mating cycles. With a appraised current of 10/5A and voltage capacity up to 500/250V, the item combines UL94-V0 fire retardancy with CE and RoHS certification, making it your go-to arrangement for secure panel-to-wire integration in unforgiving environments.
Why Choose Our LP16 Flange Mount Connector?
Superior Structural Integrity
The square spine plan with four accuracy mounting gaps disseminates mechanical push equitably over your gear walled in area. This implies you get zero connector turn amid cable control and predominant vibration resistance compared to conventional nut-fix mounts.
Fast Installation, Zero Downtime
Our pike coupling permits tool-free association changes in seconds. When your generation line needs upkeep or module substitution, you'll appreciate the time spared with this quick-locking mechanism.
Built for Extreme Conditions
The PBT housing material exceeds UL94-V0 flame-retardant standards. Your connector will maintain structural integrity when exposed to chemicals, UV radiation, and temperature extremes that would degrade standard plastic housings.
Gold-Plated Reliability
Phosphor bronze contacts with gold plating ensure contact resistance stays below 5mΩ throughout the product lifecycle. You can count on consistent electrical performance even after thousands of connection cycles.
Flexible Configuration Options
From 2-pin power applications to 9-pin signal transmission, you'll find the exact pin count for your project. The modular insert design even allows inner core replacement to adapt different configurations without replacing the entire housing.
Key Applications of LP16 Flange Mount Connector
Outdoor LED Systems
Your outdoor LED displays and landscape lighting need weatherproof connections that won't fail during heavy rain or salt spray exposure. The flange mount design creates a gas-tight seal at the panel interface, protecting both power and data transmission lines.
Industrial Automation
In robotics and CNC machinery, high-frequency vibrations can cause signal dropout with inferior connectors. The LP16 Flange Mount Connector maintains electrical continuity under extreme mechanical stress, ensuring your precision equipment operates without interruption.
Medical Equipment
Diagnostic devices require panel-mount connectivity that survives frequent sterilization and chemical cleaning. The gold-plated contacts and sealed design prevent dielectric degradation, giving you long-term reliability in clinical environments.
Renewable Energy Systems
Solar installations and EV charging infrastructure benefit from the IP68 protection rating, which guards against moisture ingress in outdoor junction boxes and distribution panels.
Technical Specifications
| Parameter | Value |
|---|---|
| Pin Configuration | 2-9P |
| Rated Current | 10A / 5A |
| Rated Voltage | 500V / 250V |
| Wire Section | 1-1.5 / 0.34-0.75mm² |
| Operating Temperature | -40℃ to +105℃ |
| Cable Diameter | Φ4-Φ9mm |
| Waterproof Rating | IP67 / IP68 |
| Mating Cycles | 2000+ |
| Housing Material | PA66 Nylon (UL94-V0) |
| Contact Material | Gold-plated copper alloy |
Installation Best Practices
Ensure a Legitimate Seal
Always utilize the given silicone gasket between the spine and your board surface. Make beyond any doubt the mounting surface is level, clean, and free from flotsam and jetsam to keep up the IP67/IP68 rating.
Cable Breadth Matching
The mating plug obliges cable external distances across from Φ4mm to Φ9mm. Utilize the high-tension tail nut and waterproof claw to secure your cable and anticipate water entrance at the cable section point.
Torque Distribution
Tighten the four mounting screws in a inclining design. This conveys weight equally and anticipates gasket misshapening that seem compromise the waterproof seal.
Why Cablein Technology?
9 A long time of Designing Excellence
Since 2017, we've specialized in waterproof interconnection arrangements for unforgiving situations. Our 6,000 ㎡ generation office in Shenzhen combines progressed fabricating gear with a group of over 200 professionals.
Global Compliance Guaranteed
Your acquirement group will appreciate that our items carry CE, RoHS, TUV, and ISO9001:2015 certifications. We handle compliance so you can center on your center business.
Custom Arrangements Available
Need a specialized stick setup or lodging fabric? Our R&D group holds over 30 utility demonstrate licenses and underpins OEM/ODM customization for one of a kind applications.
Fast Conveyance from Stock
We keep up stock levels surpassing 10,000 pieces per thing. Standard orders transport inside 7-10 days, making a difference you dodge supply chain delays.
Frequently Asked Questions
Q: Can this connector handle both control and flag transmission?
A: Yes, cross breed stick setups are accessible. You can streamline your board format by combining control and information transmission in a single item unit.
Q: What advantage does the spine mount offer over nut-fix designs?
A: The four-hole rib gives predominant torque resistance and mechanical soundness. Your connector won't turn or release amid overwhelming cable control, which is common with single-nut mounting systems.
Q: Is the lodging reasonable for changeless open air installation?
A: Completely. The PA66 nylon fabric is UV-stabilized and meets UL94-V0 fire retardancy benchmarks. Your connector will keep up execution through a long time of sun presentation and temperature cycling.
Q: How do I keep up the waterproof rating amid installation?
A: Utilize the silicone gasket given and guarantee the mounting surface is level and clean. Any surface inconsistencies can make spill ways that compromise the IP rating.
Q: What cable sizes work with the mating plug?
A: The standard arrangement obliges cable external breadths from Φ4mm to Φ9mm. The waterproof claw and tail nut secure the cable whereas keeping up natural security at the section point.
Ready to Specify the Right Connector?
Contact nick@cableinco.com to request technical specifications, confirm your pin configuration, or discuss LP16 Flange Mount Connector sample availability for your project validation.
