LP24 Solder Type Flange-Mount Waterproof Connector
2. Offers IP67 and IP68 waterproof protection for bulkhead installation.
3. Solder-type termination provides reliable wire attachment for internal connections.
4. Four-hole flange mounting ensures secure attachment to equipment enclosures.
5. Rated for -40℃ to +105℃ operating temperature with UL94-V0 flame retardant housing.
6. Tested for 2000+ mating cycles for long-term durability.
7. CE and RoHS certified, manufactured under ISO9001 quality control.
8. Custom pin count, housing material, and flange configuration available.
LP24 Solder Type Flange-Mount Waterproof Connector
The LP24 Solder Type Flange-Mount Waterproof Connector from Cablein Technology delivers enterprise-grade performance for demanding environments. This mechanical circular interconnect highlights a 24mm chassis set pattern distance across with changeless solder-cup end and a four-hole spine base. You get IP67/IP68 waterproof assurance, supporting 2-24 pins with evaluated streams up to 30A and voltages coming to 500V. The PA66 nylon lodging withstands -40℃ to +105℃ working temperatures, whereas gold-plated copper amalgam contacts guarantee contact resistance underneath 2.5mΩ. Tried for over 2000 mating cycles, this connector meets UL94-V0 fire retardancy guidelines and complies with CE and RoHS certifications.
What Makes the LP24 Solder Type Flange-Mount Waterproof Connector Different?
Your mechanical gear requests associations that won't come up short when conditions get intense. This connector fathoms basic torment focuses in high-vibration apparatus, panel-to-cable dampness entrance, and compact control conveyance in restricted spaces.
The solder-type end makes a lasting, bound together physical bond. Not at all like screw terminals that can vibrate free over time, fastened joints stay steady in 24/7 fabricating situations. You get vibration-proof unwavering quality in CNC controllers, mechanical arms, and overwhelming machinery.
The square spine plan spreads connection strengths equally over your walled in area divider. Four mounting screws pass through the rib corners, killing any hazard of revolution amid cable mating. A φ14mm fixing gasket sits between the rib and mounting surface, making a watertight obstruction that meets IP68 standards.
Technical Specifications That Matter
Material Excellence
The shell employments high-performance PBT plastic or zinc combination with nickel plating. You get UL94-V0 fire retardancy and predominant erosion resistance. Gold-plated copper amalgam contacts minimize oxidation and guarantee tall conductivity for a long time of steady operation.
Electrical Performance
- Rated current: 5A to 30A (varies by pin count)
- Rated voltage: 250V to 500V
- Wire section support: 0.5mm² to 4mm²
- Contact resistance: < 2.5mΩ
- Insulation resistance: > 500MΩ
Environmental Protection
The connector withstands salt spray exposure for 48-72 hours. Thermal cycling tests from -40℃ to +105℃ verify field performance. You can trust this LP24 Solder Type Flange-Mount Waterproof Connector in outdoor, marine, and industrial automation applications.
Where This Connector Excels
Marine and Submersible Electronics
Shipboard control panels and underwater sensor arrays demand pressurized seals against saltwater ingress. The flange-mount design ensures watertight integrity even when submerged.
Outdoor LED Systems
Large-scale outdoor displays and traffic signaling systems face heavy rain, UV radiation, and temperature swings. This connector maintains power and data integrity through all weather conditions.
Industrial Automation
CNC controllers and robotic arms operate 24/7 in dusty, vibrating environments. The permanent solder connection prevents terminal loosening that causes costly downtime.
Renewable Energy
Solar energy systems and EV charging stations need connectors that survive years outdoors. The corrosion-resistant materials and IP68 rating protect your investment.
Installation and Maintenance Advantages
Front-Mount Installation
You can install the receptacle from outside the panel before internal wiring begins. This speeds up assembly in crowded equipment enclosures.
Secure Attachment
The four-hole flange pattern works with standard mounting hardware. You don't need special tools or custom brackets.
Long Service Life
Tested for over 500 mating cycles at minimum, with 2000+ cycles achievable under normal conditions. The gold plating on contacts resists wear during repeated connections.
Customization Options
Need a specific pin count or housing material? Cablein offers custom configurations including 2-24 pins, zinc alloy or PBT plastic housings, and modified flange patterns.
Quality Control You Can Trust
Every LP24 Solder Type Flange-Mount Waterproof Connector undergoes strict testing protocols:
Hermeticity Testing
Vacuum and water immersion tests verify IP67/IP68 ratings before shipping. Your equipment stays dry even in flooded conditions.
Electrical Integrity
High-voltage dielectric withstanding tests catch potential short circuits. Insulation resistance monitoring ensures > 500MΩ performance.
Environmental Stress Screening
Salt spray corrosion testing simulates years of coastal exposure. Thermal cycling from -40°C to +80°C proves reliability in extreme climates.
Mechanical Validation
Insertion and extraction force testing ensures smooth operation. Solderability inspections verify gold-plating thickness meets industry standards for low-latency transmission.
All processes comply with ISO9001:2015 quality management systems. You get 100% inspection for waterproof performance, durability, and electrical reliability.
Frequently Asked Questions
Q1: What wire gage is prescribed for the LP24 patch terminals?
A: Depending on the stick arrangement, it for the most part bolsters 12 AWG to 20 AWG wires. Continuously guarantee the patch joint does not surpass the glass breadth to keep up clearance.
Q2: Can the rib gasket be reused after maintenance?
A: We exceedingly suggest supplanting the silicone gasket if it appears signs of compression set or tearing to keep up the IP68 seal.
Q3: How does the patch sort compare to screw terminals for vibration resistance?
A: Patch associations are prevalent for high-vibration situations. They make a bound together physical bond that cannot vibrate free over time.
Q4: Is this connector congruous with metal and plastic adaptations of the same series?
A: Yes, the LP24 arrangement highlights standardized mating interfacing. You can inter-mate plastic and metal lodging variants.
Q5: Does the connector back PoE or high-speed data?
A: Whereas basically utilized for control and flag, particular multi-pin setups can bolster information transmission. Guarantee cable protecting is accurately overseen through the connector body.
Why Choose Cablein Technology?
Since 2017, we've helped customers in over 100 countries solve connectivity challenges. Our 6,000 ㎡ facility in Shenzhen produces over 10,000 pieces per item in stable inventory. You get standard delivery within 7-10 days.
Our professional team offers 24-hour technical support and end-to-end project assistance. With over 30 utility model patents and 9 years of industry experience, we handle OEM/ODM customization and private mold development for specialized applications.
Ready to Upgrade Your Connections?
Contact us at nick@cableinco.com to download technical specifications, request samples, or confirm your LP24 Solder Type Flange-Mount Waterproof Connector requirements.
