LP24 Solder Type Panel-Mount Waterproof Connector
2. Provides IP67 and IP68 waterproof sealing at the panel mounting point.
3. Solder-type rear entry allows secure internal wiring for equipment pass-through.
4. Snap-lock coupling enables quick connection from outside the panel.
5. Rated for -40℃ to +105℃ temperature range with UL94-V0 flame retardant housing.
6. Tested for 2000+ mating cycles for consistent performance.
7. TUV and CE certified under ISO9001 and RoHS compliance.
8. Custom pin configuration, housing material, and panel cutout size available.
LP24 Solder Type Panel-Mount Waterproof Connector – Industrial-Grade Connectivity Solution
When your equipment needs reliable pass-through connectivity in harsh environments, the LP24 Solder Type Panel-Mount Waterproof Connector delivers enterprise-grade performance. Designed by Cablein Innovation, this connector highlights IP67/IP68 waterproof appraisals, gold-plated copper amalgam contacts, and a PA66 nylon lodging with UL94-V0 fire retardancy. It bolsters 2-24 stick setups, works over -40℃ to +105℃, and offers appraised streams up to 30A at 500V. With 2000+ mating cycles tried and TUV/CE certification, you get changeless solder-type end that withstands vibration, dampness, and requesting mechanical conditions.
What Is the LP24 Solder Type Panel-Mount Waterproof Connector?
The LP24 Solder Type Panel-Mount Waterproof Connector is a high-performance circular interconnect solution designed for chassis-to-cable integration in demanding environments. You get a robust multi-pin configuration with gold-plated solder contacts that ensure permanent, vibration-resistant electrical conductivity.
This connector tackles basic industry torment focuses. Flag constriction in high-humidity zones? Disposed of. Mechanical disappointment from hub pull-out powers? Avoided. Require for space-efficient board thickness? Addressed.
The high-speed pike locking component dispenses with inadvertent disengagement. You won't confront the dangers common in standard consumer-grade interfacing. Instep, you get a secure IP67/IP68-rated seal for both control and information transmission.
Key Technical Properties of LP24 Solder Type Panel-Mount Waterproof Connector
Technical specifications are engineered for industrial longevity:
Housing Materials:
- High-performance PBT with UL94-V0 flame retardancy
- Zinc alloy option with chrome plating for EMI shielding
Critical Parameters:
- Contact Resistance: <2.5mΩ to minimize heat buildup
- Rated Current/Voltage: 5A to 30A at 250V-500V AC
- Insulation Resistance: >500MΩ at 500V DC
- Durability: Over 2000 mating cycles
- Temperature Range: -40°C to +105°C
- Wire Section: 0.5mm² to 4mm²
The solder-type termination provides superior tensile strength and electrical stability compared to crimp-style alternatives. This matters especially in high-vibration machinery where connection integrity is non-negotiable.
Installation Advantages You'll Appreciate
Simple Panel Integration:
Installing this connector requires only a single round panel cutout and a rear-mounted locking nut for secure fixation. You save time and reduce installation complexity.
Superior Sealing:
A silicone sealing ring sits between the housing and panel face, blocking moisture entry at the mounting point. Your equipment stays protected even under direct water exposure.
Protective Features:
An included dust cap protects the unmated receptacle from debris and moisture when equipment is disconnected. You maintain connection integrity during storage and transport.
Flexible Wiring:
Solder cup contacts on the rear side accept pre-tinned wires, making internal chassis wiring straightforward. You get permanent connections that won't loosen over time.
Material Options:
The panel-mount design works with either zinc alloy for ruggedness or PBT plastic for cost-sensitive builds. You choose based on your specific application requirements.
Scalable Configurations:
Receptacles are available with contact counts ranging from 2 to 24 pins. Whether you need simple power feeds or complex signal arrays, you're covered.
Primary Applications of LP24 Solder Type Panel-Mount Waterproof Connector
Industrial Automation and Robotics:
This connector serves as the primary control interface for CNC machinery where exposure to cutting fluids and heavy vibration is constant. You get reliable operation in the harshest factory environments.
Outdoor LED Display and Lighting Systems:
It provides a UV-resistant and weather-sealed power link that prevents water ingress during high-pressure cleaning or extreme storms. Your lighting systems stay operational regardless of weather conditions.
Medical Equipment and Laboratory Devices:
The connector's stable solder joints and chemical-resistant housing allow for reliable performance in sterilized environments. You maintain precise signal integrity for diagnostic data even with frequent disinfectant wiping.
Additional Industries:
- Solar energy and EV charging systems
- Energy storage equipment enclosures
- Security and surveillance installations
- Rail transportation control panels
- Underwater robotics and marine applications
Frequently Asked Questions
Q1: Why select patch sort over pleat for the LP24 connector?
A: Patch sorts give a gas-tight, changeless association that offers lower resistance and higher unwavering quality in high-vibration situations where crimps might release over time.
Q2: Can the item handle both flag and power?
A: Yes, multi-core setups (from 2 to 24 pins) permit for half breed setups. Be that as it may, current evaluations per stick must be entirely watched for secure operation.
Q3: What is the suggested wire gage for this connector?
A: It regularly underpins 12-20 AWG wires (0.5mm² to 4mm²) depending on the particular stick tally and current stack requirements.
Q4: How is the waterproof rating kept up at the board interface?
A: It utilizes a high-elasticity elastic gasket and a rear-nut locking framework to guarantee the mounting gap itself remains fixed against dampness ingress.
Q5: Is the connector safe to UV exposure?
A: Yes, the PBT plastic utilized in the LP arrangement is UV-stabilized, avoiding brittleness and discoloration amid long-term open air deployment.
Q6: Can I customize the stick configuration?
A: Completely. Cablein offers custom stick setups, lodging materials, and board set pattern sizes to coordinate your particular application needs.
Q7: What certifications does this connector hold?
A: The LP24 arrangement is TUV and CE certified, fabricated beneath ISO9001:2015 benchmarks, and complies with RoHS requirements.
Why Choose Cablein for Your Connectivity Needs?
With 9 years of specialized experience in industrial waterproof connectors, Cablein Technology provides more than just products. You gain access to:
- Advanced R&D capabilities with over 30 utility model patents
- Strict quality control with 100% waterproof performance testing
- Fast delivery with stable inventory exceeding 10,000 pieces per item
- Professional technical support available 24/7
- Flexible customization for OEM/ODM and private mold development
Our 6,000 ㎡ production facility and team of over 200 professionals ensure you receive consistent quality and reliable delivery timelines.
