QC16 Quick Clamp Waterproof Connector
2. Offers IP67 and IP68 waterproof ratings for medium-power field wiring.
3. Quick clamp mechanism requires only a simple twist to secure the cable.
4. Suitable for industrial power supplies, outdoor LED drivers, and renewable energy gear.
5. Tool-free screw termination reduces installation time and complexity.
6. CE and RoHS certified, manufactured under ISO9001 quality control.
7. Engineered for reliable performance in demanding conditions.
8. We offer custom pin configurations and complete cable assembly services.
QC16 Quick Clamp Waterproof Connector – Fast, Reliable Field Wiring Solution
The QC16 Quick Clamp Waterproof Connector from Cablein Technology delivers enterprise-grade performance with IP67/IP68 protection. Built from PA66 nylon with gold-plated brass contacts, it handles up to 500V DC/AC and 15A over 2-4 contacts. The tool-free speedy clamp instrument locks cables in seconds with a basic bend. Working from -40℃ to 105℃, it fits cable distances across of 4.5-9.2mm. CE and RoHS certified beneath ISO9001:2015 quality control, this connector guarantees steady execution in open air Driven frameworks, mechanical mechanization, and renewable vitality installations.
What Makes the QC16 Quick Clamp Waterproof Connector Different?
Traditional screw terminals waste your time and create weak points. The QC16 Quick Clamp Waterproof Connector solves that problem with a spring-loaded clamping architecture.
You simply insert stripped wires and twist the housing. No tools needed. No torque guesswork.
This design eliminates two common field failures:
- Wire creep from thermal cycling
- Inconsistent sealing from incorrect screw tension
The quick clamp maintains constant contact pressure through vibration and temperature swings. Whether you're working in a dusty factory or a rain-soaked installation site, you get consistent, gas-tight connections every time.
It's engineered for professionals who need fast deployment without callbacks.
Technical Specifications That Matter
Here's what you're working with:
| Parameter | Specification |
|---|---|
| Rated Voltage & Current | 2/3/4P: 500V, 15A/8A; A+B: 500V, 8A+3A; 5-12P: 100V, 8A/3A |
| IP Rating | IP67 / IP68 |
| Dielectric Strength | DC 1KV, 2mA, 60s |
| Insulation Resistance | ≥200MΩ at DC 500V |
| Operating Temperature | -40℃ to 105℃ |
| Cable Diameter Range | 4.5-9.2mm |
| Housing Material | PA66 Nylon with UL94-V0 flame rating |
| Contact Material | Gold-plated brass |
The dual silicone O-rings create a waterproof barrier that meets IEC 60529 standards. You can submerge it in water jets or bury it in wet soil—it keeps working.
The PA66 housing resists UV degradation and chemical exposure. It won't crack under mechanical impact on factory floors.
Gold-plated contacts minimize oxidation and contact resistance, giving you stable power delivery over years of service.
Six Reasons Installers Choose This Connector
1. Quarter-Turn Locking
Engage the clamp with a smooth 90-degree revolution. No bungling with screwdrivers in tight spaces.
2. Demonstrated IP67 Waterproofing
Dual fixing rings piece tidy and high-pressure water planes. Idealize for open air walled in areas and washdown zones.
3. Adaptable Wire Termination
Screw terminals acknowledge wire gages from 0.5mm² to 2.5mm² (20-14 AWG), both strong and stranded.
4. Impact-Resistant Housing
Reinforced PA66 withstands drops, kicks, and chemical sprinkles in mechanical environments.
5. Cross-Compatible Design
Matches standard QC16 board set patterns. You can swap brands without retooling your installations.
6. Wide Temperature Range
From cooler stockrooms to housetop sun based clusters, it works dependably in extremes.
Where You'll Use It
Outdoor LED & Architectural Lighting
Street lights, tunnel illumination, and stadium fixtures demand vibration-proof connections. The quick clamp stays tight through wind sway and thermal expansion.
Industrial Automation & Sensors
Food processing plants require IP69K-rated connectors for high-pressure washdowns. The QC16 Quick Clamp Waterproof Connector handles frequent cleanings without degrading seals.
Renewable Energy Systems
Solar panel junction boxes and wind turbine control circuits benefit from tool-free field wiring. You reduce labor costs and speed up commissioning.
Marine & Aquaculture
Offshore buoys and underwater sensors need corrosion-resistant, easy-to-service connectors. The quick clamp lets maintenance crews rewire in heavy seas without precision tools.
Quality Control You Can Trust
Cablein's quality handle covers four basic areas:
Ingress Security Verification
Every bunch experiences vacuum spill testing and pressurized water inundation. We approve silicone gasket keenness some time recently shipping.
Mechanical Pull-Force Testing
We confirm the quick-clamp meets IEC 60998-2-2 benchmarks. Wires won't drag out beneath field stress.
Electrical Integrity
Routine dielectric withstand voltage tests and separator resistance checks (>100MΩ at 500V DC) guarantee secure operation.
Environmental Stretch Screening
96-hour salt shower and warm stun tests affirm the PA66 lodging and inside springs keep up pressure over a 10-year benefit life.
This four-layer approach ensures long-term field performance.
Frequently Asked Questions
Q: What wire sizes work with this connector?
A: It acknowledges 0.5mm² to 2.5mm² (20-14 AWG), both strong and stranded wires.
Q: Can I reuse the connector amid maintenance?
A: Yes. The spring-clamp component underpins different mating cycles without losing contact force.
Q: How does it handle vibration?
A: The inner spring keeps up consistent pressure, outflanking screw terminals that release over time.
Q: Is it chemical-resistant?
A: PA66 lodging and silicone seals stand up to mechanical oils, cleansers, and weakened acids.
Q: What certifications does it carry?
A: CE, RoHS, and made beneath ISO9001:2015 quality benchmarks. Accessible with TUV certification for select series.
Q: What's the greatest submersion depth?
A: IP68-rated forms back nonstop submersion up to 10 meters.
Ready to Simplify Your Next Installation?
Contact us at nick@cableinco.com to request technical specifications, confirm pin configurations, or discuss custom cable assemblies. We're here to support your QC16 Quick Clamp Waterproof Connector needs.
