500V IP67 Waterproof Circular Connector M16 Threaded Butt Type for Secure Outdoor Connections

Brand Name:	Cablein
Model Number:	CB-M16-MDF01-3P-X
MOQ:	1PCS
Price:	Price Can Contact With Our Sales
Packaging Details:	High Quality export carton
Payment Terms:	T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen China

Certification:

CE, ROHS, TUV , ETL

Name:

M16 IP67 500V Threaded Butt Type Waterproof Circular Connector

Metal:

Gilded Brass

Material:

PA6 Nylon

Insertion Life:

1000 Times

Voltage:

Waterproof:

Highlight:

Waterproof Circular Cable Connectors

500V Circular Cable Connectors

Waterproof Cable Connectors M16

Product Description

500V Waterproof Circular Cable Connectors IP67 M16 Threaded Butt Type

Product Overview

High-performance M16 IP67 rated circular connectors designed for demanding industrial applications requiring reliable waterproof protection and secure threaded connections.

Pin Configuration: 3Pin Male/Female Connector

Current Rating: 8A+3A Max

Material: PA6 Nylon

Connection Type: Threaded Butt Type

Operating Voltage: 500V

Wire Assembly: Soldering or screw fitting

UV Resistance: Outdoor Rated

Cable Jacket OD: 4-8 mm²

Technical Specifications

Pins Number	2Pins	3Pins	4Pins	5Pins	2+3Pins	6Pins	2+4Pins	3+3Pins	8Pins	10Pins	12Pins
Rated Voltage	500V	500V	500V	500V	500V	500V	500V	100V	100V	100V
Rated Current	8A	8A	8A	8A	8A+3A	3A	8A+3A	3A	3A	3A	3A
Insulation Voltage	3KV	3KV	1KV	1KV	1KV	1KV	1KV	1KV	1KV	1KV	1KV
DC 500V Insulation Resistance	200MΩ	200MΩ	200MΩ	200MΩ	200MΩ	200MΩ	200MΩ	200MΩ	200MΩ	200MΩ	200MΩ
IP CODE	IP67	IP67	IP67	IP67	IP67	IP67	IP67	IP67	IP67	IP67	IP67
Cable Specifications	≤1mm²	≤1mm²	≤1mm²	≤1mm²	≤1.5+0.3mm²	≤1mm²	≤0.75mm²	≤1.5+0.3mm²	≤0.5mm²	≤0.5mm²	≤0.5mm²
Assembly Cable Diameter	4.5-9.2mm²	4.5-4.5-9.2mm²	4.5-9.2mm²	4.5-4.5-9.2mm²	4.5-4.5-9.2mm²	4.5-4.5-9.2mm²	4.5-4.5-9.2mm²	4.5-4.5-9.2mm²	4.5-4.5-9.2mm²	4.5-4.5-9.2mm²

Key Advantages

Easy plug-and-play assembly with reliable environmental protection featuring multiple waterproofing levels including o-rings, waterproof sealant, and flexible end seals
IP67 waterproof rating ensures complete protection against dust and water immersion
Simple installation requiring only a screwdriver for wire connection
Available in both screw fitting and soldering versions to suit different application requirements
Designed for quick disconnect by unscrewing the main body and separating the two ends

Product Drawing
