IP68 Nylon Coated M8 Waterproof Male Female Connector for Smart Agricultural Machine Controller

Brand Name: Cablein
Model Number: CB-M8-MDF11-2P-X
MOQ: 1PCS
Price: Price Can Contact With Our Sales
Packaging Details: High Quality export carton
Payment Terms: T/T,Western Union
Detail Information
Product Description
Detail Information
Place of Origin:
Shenzhen China
Certification:
CE, ROHS, TUV , ETL
Mechanical Life:
3000 Times
Wiring:
Soldering
Ip Level:
IP68
Model:
M8 Waterproof Connector
Cable Length:
Customized
Connecting:
Screw Locking
Operating Temperature:
-40°C To 105°C
Gender:
Male/Female
Highlight:

Nylon Coated Waterproof Male Female Connector

,

M8 Waterproof Male Female Connector

,

Nylon M8 Waterproof Connector

Product Description
Nylon Coated M8 Waterproof Male Female Connector Smart Agricultural Machine Controller
Product Specifications
  • Pin Configuration: 2/3/4 Pins Male Female Connector
  • Current Rating: 3A Maximum
  • Material: PA66 Nylon
  • Connection Type: Screw-less waterproof connector
  • Operating Voltage: 60V
  • Assembly Method: Soldering or screw fitting
  • UV Resistance: Outdoor rated
  • Cable Jacket OD: 2-6 mm
Technical Specifications
Parameter 2 Pins 3 Pins 4 Pins
Rated Voltage 60V 60V 60V
Rated Current 3A 3A 3A
Insulation Voltage 1KV 1KV 1KV
DC 500V Insulation Resistance 200MΩ 200MΩ 200MΩ
IP Code IP67 IP67 IP67
Cable Specifications ≤0.75mm² ≤0.75mm² ≤0.75mm²
Assembly Cable Diameter 2-6mm 2-6mm 2-6mm
Product Features & Benefits
IP68 Nylon Coated M8 Waterproof Male Female Connector for Smart Agricultural Machine Controller 0
The M8 Nylon-Coated Waterproof Male Female Connector is engineered for smart agricultural machine controllers, providing reliable performance in demanding environmental conditions. The IP67 waterproof rating ensures protection against moisture and potential damage.
Designed for durability and efficiency, this connector features quick and secure connections that enhance agricultural machinery functionality. The nylon coating provides additional protection against abrasion and corrosion.
The smart design and high-quality construction simplify installation processes while minimizing connection failures, making it an optimal choice for improving performance and longevity in smart agricultural applications.
Technical Drawing
IP68 Nylon Coated M8 Waterproof Male Female Connector for Smart Agricultural Machine Controller 1
Frequently Asked Questions
What types of waterproof connectors do you offer?
We provide comprehensive waterproof connector series, including private mold and customized solutions. Our expertise covers LED waterproof connectors, assembly waterproof connectors, over-mold connectors, T-connectors, Y-customized connectors, livestock and poultry industry connectors, new energy connectors, and solar system connectors.
How can I purchase your products?
Contact our sales team online or via email. Please provide:
  • Current rating and number of contacts required
  • Preferred assembly style
  • Cable wire gauge specifications
  • Cable length and shipping preferences
How can I contact your team?
Please reach out via email, phone, Skype, or WhatsApp. With over 8 years of industry experience, our professional sales and R&D teams can quickly understand and resolve your technical requirements.
Are samples available?
Yes, we provide samples with freight costs covered by the customer. Please provide your courier account number and detailed shipping address for immediate sample dispatch.
