IP68 Waterproof Male Female Connector with 500V Rating and Self-Locking Mechanism for Outdoor Use

Brand Name:	Cablein
Model Number:	CB-P16-MDF11-43P-X
MOQ:	1PCS
Price:	Price Can Contact With Our Sales
Packaging Details:	High Quality export carton
Payment Terms:	T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen China

Certification:

CE, ROHS, TUV , ETL

Ip Level:

Withstanding Voltage:

Cable Length:

Custom

Type:

Adapter

Lead Time:

10-15 Days

Cable Diameter:

12mm Max

Package:

Carton

Material Of Pin:

Copper Alloy

Highlight:

Waterproof Electrical Male Female Connectors

IP68 Electrical Male Female Connectors

Product Description

P16 Waterproof IP68 Electrical Connectors for Plant Growth Lights

High-quality self-locking male and female connectors designed specifically for plant growth lighting systems. These waterproof connectors ensure reliable performance in various environmental conditions.

Product Specifications

Specification	2 Pins	3 Pins	4 Pins	8 Pins
Rated Voltage	500V	500V	500V	110V
Rated Current	15A	15A	15A	5A
Insulation Voltage	3KV	3KV	1KV	1KV
DC 500V Insulation Resistance	500MΩ	500MΩ	500MΩ	500MΩ
IP Code	IP67	IP67	IP67	IP67
Cable Specifications	≤1.5mm²	≤1.5mm²	≤1.0mm²	≤0.75mm²
Assembly Cable Diameter	4.5-9.2mm	4.5-9.2mm	4.5-9.2mm	4.5-9.2mm

Key Features

Material: PA66 Nylon for durability and UV resistance
Current Rating: 15A Maximum
Connection Type: Screw-less waterproof design
Assembly Options: Soldering or screw fitting
Cable Jacket OD: 4.5-9.2 mm compatibility
Self-locking mechanism for secure connections
Waterproof IP67/IP68 rating for outdoor use
UV resistant for long-term outdoor performance

Product Diagram

Frequently Asked Questions

What types of waterproof connectors do you offer?

We provide a comprehensive range of waterproof connectors including P16 self-locking connectors, assembly waterproof connectors, over-mold connectors, T-connectors, Y-customized connectors, and specialized connectors for livestock, poultry, and new energy applications including solar systems.

How do I purchase your products?

Contact our sales team online or by email. Please provide: current rating and number of contacts, assembly style preference, cable wire gauge specifications, cable length requirements, and preferred shipping method.

How can I contact you?

Please provide your email, phone number, Skype, or WhatsApp ID. Our experienced team with over 8 years in the industry can quickly address your technical questions and provide professional support.

Can I request samples?

Yes, we're pleased to provide samples. You only need to cover the freight cost. Please provide your courier account number and detailed shipping address for immediate sample dispatch.
