3 Pin IP68 Waterproof Power Connector with Push Locking and PA66 Nylon for Outdoor LED Lights

Brand Name:	Cablein
Model Number:	CB-LP12-3P
MOQ:	1PCS
Price:	Price Can Contact With Our Sales
Packaging Details:	High Quality export carton
Payment Terms:	T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen China

Certification:

CE, ROHS, TUV , ETL

Temperature Range:

-40-105℃

Material:

PA66 Nylon

Insertion Life:

1000 Times

Circuit Type:

Series Circuit

Ip Rating:

Connecting Model:

Push Locking

Coupling:

Threaded

Applications:

Outdoor Decoration, LED Lights

Highlight:

3 Pin Watertight Power Connector

Watertight Power Connector Push Locking

Product Description

3 Pin Watertight Power Connector Push Locking IP68 Plastic Wiring Screw

High-performance circular waterproof connector designed for industrial applications requiring reliable power connections in demanding environments.

Product Specifications

Pin Configuration: 2/3/4/5/7/9/12 Male/Female

Current Rating: 10A Maximum

Material: PA66 Nylon

Operating Voltage: 400V

Connection Type: Screw-less Waterproof

Wire Assembly: Soldering or Screw Fitting

Cable Jacket OD: 4-9mm

UV Resistance: Certified Pass

Technical Datasheet

Part No.	CB-LP16-2P	CB-LP16-3P	CB-LP16-4P	CB-LP16-5P	CB-LP16-7P	CB-LP16-9P
Pins	2 Pin	3 Pin	4 Pin	5 Pin	7 Pin	9 Pin
Bonding Wire	✓	✓	✓	✓	✓	✓
Locking Wire	✓	✓	✓	✓	*	*
Contact Member (Bonding)	φ2.7*2	φ2.7*3	φ2.7*4	φ1.8*5	φ1.8*7	φ1.0*9
Contact Member (Locking)	φ2.4*2	φ2.4*3	φ2.4*4	φ1.8*5	*	*
Applicable Wire Gauge	1.5mm² / 16AWG	0.5mm² / 20AWG	0.5mm² / 20AWG	-
Rated Current	15A	5A	5A	-
Rated Voltage	400V AC	250V AC	250V AC	-

Additional Specifications

Insulation Voltage: 2000V AC / 1500V AC

Contact Impedance: < 3 mΩ / < 5 mΩ

Temperature Rise: 20A 30℃↓; 25A 40℃↓; 30A 50℃↓

Insulation Resistance: ≥ 1000 MΩ

Mechanical Life: ≥ 1900 Times

Ambient Temperature: -40℃ to +85℃

High Temperature Aging: 85℃ / 168h

Product Advantages

Engineered for solar systems and demanding industrial applications, the LP-16-3 connector delivers exceptional reliability and durability. The IP68 waterproof rating ensures secure power connections in all weather conditions, protecting against rain, humidity, and environmental contaminants.

The circular design provides optimal fit and connection stability, minimizing power loss and ensuring efficient electrical transmission. Constructed from PA66 nylon plastic, the connector offers excellent insulation properties, enhanced safety, and lightweight durability that withstands installation and maintenance demands.

Built to endure harsh environmental conditions, this connector maintains performance under high temperatures and UV exposure, ensuring long service life and reduced maintenance costs for solar systems and outdoor equipment.

Applications

Ideal for solar power systems, outdoor electrical equipment, industrial machinery, and any application requiring reliable waterproof power connections in challenging environments.

Frequently Asked Questions

What type of waterproof connectors do you have?

We offer comprehensive waterproof connector solutions including P16 Self-Locking Injection Waterproof Connectors, Assembly waterproof connectors, Over-mold connectors, T-connectors, Y-custom connectors, and specialized solutions for livestock/poultry industries, new energy applications, and solar systems.

How to buy your products?

Contact our sales team online or by email with the following details:

Current rating and number of contacts required
Assembly style preference
Cable wire gauge specifications
Cable length and shipping requirements

How to contact you?

Please provide your email, phone number, Skype, or WhatsApp ID. Our experienced team with over 8 years in the industry can quickly address your requirements and provide professional support.

Can I get samples?

Yes, we provide samples with freight cost coverage only. Please share your courier account details and delivery address for immediate sample dispatch.
