IP68 Waterproof M19 Cable Connector with 500V Operating Voltage and PA66 Nylon Material for Secure Power Connections

Brand Name:	Cablein
Model Number:	CB-GX19-12
MOQ:	1PCS
Price:	Price Can Contact With Our Sales
Packaging Details:	High Quality export carton
Payment Terms:	T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen China

Certification:

CE, ROHS, TUV , ETL

Application:

Data Acquisition

Shipping Methods:

DHL , FedEx , UPS , TNT

Custom:

Mold Material:

Ip Level:

Operating Temperature:

-40°C To 105°C

Connection Mode:

Screw Threaded

Cable Gauge:

14 AWG

Highlight:

IP68 Waterproof Power Cable Connector

M19 Waterproof Power Cable Connector

Waterproof Electrical Cable Connectors

Product Description

IP68 Waterproof Power Cable Connector Female Head M19 Wiring Harness

Factory direct GX20 aviation female head M19 cable head wiring harness factory plug power plug with superior electrical conductivity and durability for reliable power connectivity.

Product Specifications

Pin Configuration: 2/3/4/5/7/9/12 Male/Female Connector

Current Rating: 20A Max

Material: PA66 Nylon

Connection Type: Screw-less waterproof connector

Operating Voltage: 500V

Assembly Method: Soldering or screw fitting

UV Resistance: Outdoor rated

Cable Jacket OD: 4.5-9.2mm

Technical Data Sheet

Part No.	CB-LP20-2P	CB-LP20-3P	CB-LP20-4P	CB-LP20-5P	CB-LP20-7P	CB-LP20-9P	CB-LP20-12P
Pins	2 Pin	3 Pin	4 Pin	5 Pin	7 Pin	9 Pin	12 Pin
Wire Connection - Bonding	✓	✓	✓	✓	✓	✓	✓
Wire Connection - Locking	✓	✓	✓	✓	*	*	*
Contact Member - Bonding	φ2.7*2	φ2.7*3	φ2.7*4	φ1.8*5	φ1.8*7	φ1.0*9	φ1.0*12
Contact Member - Locking	φ2.4*2	φ2.4*3	φ2.4*4	φ1.8*5	*	*	*

Performance Specifications

Applicable Wire Gauge: 2.5-4 mm² (14-12 AWG), 1-1.5 mm² (18-16 AWG), 0.34-0.75 mm² (22-20 AWG)

Rated Current: 20A, 10A, 5A

Rated Voltage: 500V AC, 500V AC, 250V AC

Insulation Voltage: 2500V AC, 2000V AC, 1500V AC

Contact Impedance: <1 mΩ, <3 mΩ, <5 mΩ

Temperature Rise: 20A 30℃↓; 25A 40℃↓; 30A 50℃↓

Insulation Resistance: ≥1000 MΩ

Mechanical Life: ≥1900 Cycles

Ambient Temperature: -40℃ to +85℃

High Temperature Aging: 85℃ / 168 hours

Product Advantages

The GX20 aviation female head M19 cable head wiring harness provides reliable and efficient connectivity for demanding applications. The precision-engineered design ensures a secure, snug fit that minimizes loose connections and maintains stable power supply.

Built to withstand rigorous industrial conditions and frequent use, this factory-direct plug offers superior electrical conductivity and exceptional durability. Suitable for industrial machinery, advanced electronics, and various professional applications requiring dependable power connectivity.

Applications

Ideal for industrial machinery, automation systems, advanced electronics, outdoor equipment, and any application requiring reliable waterproof power connectivity in challenging environments.

Frequently Asked Questions

What type of waterproof connectors do you have?

We offer comprehensive waterproof connector solutions including LP20 welded 7-core male plug with flange female socket, assembly waterproof connectors, over-mold waterproof connectors, T and Y customized connectors, livestock industry connectors, poultry industry connectors, new energy waterproof connectors, and solar system waterproof connectors. Many types feature our private molds and custom designs.

How to buy your products?

Contact our sales team online or by email with the following details:

Confirm current rating and number of contacts
Specify assembly style requirements
Provide cable wire gauge specifications
Indicate cable length and preferred shipping method

How to contact with you?

Please provide your email, phone number, Skype, or WhatsApp ID. With over 8 years of industry experience, our professional sales and R&D team can quickly understand your requirements and provide effective solutions. We're available to answer any questions and address your specific needs.
