IP68 Waterproof Power Connector with 500V Voltage and PA66 Nylon Material for Aviation Plug Socket LD20

Brand Name:	Cablein
Model Number:	CB-LD20
MOQ:	1PCS
Price:	Price Can Contact With Our Sales
Packaging Details:	High Quality export carton
Payment Terms:	T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen China

Certification:

CE, ROHS, TUV , ETL

Name:

Welding Free Aviation Plug Socket LD20 Waterproof Power Connector

Temperature Range:

-40-105℃

Material:

PA66 Nylon

Insertion Life:

1000 Times

Voltage:

Waterproof:

Highlight:

Welding Free Waterproof Power Connector

Waterproof Power Connector IP68

Product Description

Welding Free Waterproof Power Connector IP68 Aviation Plug Socket LD20

Advanced waterproof power connector designed for industrial applications with IP68 rating and welding-free installation.

Product Specifications

Pin Options: 2/3/4/5/7/9/12 Male Female Connector

Current Rating: 35A Max

Material: PA66 Nylon

Connection Method: Screw-less type waterproof connector

Operating Voltage: 500V

Assembly Wire: Soldering or screw fitting

Outdoor UV Resistance: Pass

Cable Jacket OD: 9.5-14mm

Technical Datasheet

Part No.	CB-LD20-2P	CB-LD20-3P	CB-LD20-4P	CB-LD20-5P	CB-LD20-7P	CB-LD20-9P
Pins	2 Pin	3 Pin	4 Pin	5 Pin	7 Pin	9 Pin
Wire Connection - Bonding	✓	✓	✓	✓	✓	✓
Wire Connection - Locking	✓	✓	✓	✓	*	*
Contact Member - Bonding Wire	φ2.7*2	φ2.7*3	φ2.7*4	φ1.8*5	φ1.8*7	φ1.0*9
Contact Member - Locking Wire	φ2.4*2	φ2.4*3	φ2.4*4	φ1.8*5	*	*
Applicable Wire Gauge	1.5mm² / 16AWG	0.5mm² / 20AWG	0.5mm² / 20AWG
Rated Current	35A	25A	5A
Rated Voltage	500V AC	400V AC	250V AC
Insulation Voltage	2000V AC	1500V AC	1500V AC
Contact Impedance	< 1 mΩ	< 3 mΩ	< 5 mΩ

Temperature Rise: 20A 30℃↓; 25A 40℃↓; 30A 50℃↓ | 10A 30℃↓; 15A 40℃↓; 20A 50℃↓ | 5A 30℃↓; 7A 40℃↓; 10A 50℃↓

Insulation Resistance: ≥ 1000 MΩ

Mechanical Life: ≥ 1900 Times

Ambient Temperature: -40～+85 ℃

High Temperature Aging: 85 ℃ / 168 h

Product Advantages

The Welding Free Aviation Plug Socket LD20 waterproof power connector sets new standards in power connection technology with advanced waterproof features that ensure reliable performance in harsh environments. Engineered to withstand rain, moisture, and challenging conditions, this connector maintains uninterrupted power flow while eliminating the need for welding during installation.

Constructed from robust, high-quality materials, the LD20 connector offers exceptional durability for long-term use across aviation, automotive, and industrial applications. Its secure and stable connection design ensures efficient power transfer without compromising safety.

Applications

Ideal for industrial equipment, aviation systems, automotive applications, outdoor electrical installations, and any environment requiring reliable waterproof power connections.
