M20 Waterproof Cable Connector Female Extension with IP44 Rating 16A Capacity and PA66 Nylon Material

Brand Name: Cablein
Model Number: CB-P16-MDF12
MOQ: 1PCS
Price: Price Can Contact With Our Sales
Packaging Details: High Quality export carton
Payment Terms: T/T,Western Union
Detail Information
Product Description
Detail Information
Place of Origin:
Shenzhen China
Certification:
CE, ROHS, TUV , ETL
Name:
IP44 Waterproof Connector 16A M20 Female Extension Cable Waterproof Connector
Temperature Range:
-40-105℃
Material:
PA66 Nylon
Insertion Life:
1000 Times
Voltage:
500V
Waterproof:
IP68
Highlight:

Waterproof Cable Connector IP44

,

Waterproof Cable Connector 16A

,

M20 Female Cable Connector

Product Description
M20 Waterproof Cable Connector Three Straight IP44 16A Female Extension
Product Overview
This M20 waterproof connector provides reliable protection in various environments with IP44 rating for excellent waterproof and dustproof capabilities.
Technical Specifications
Pin Configuration: 2/3/4/8 Pins Male/Female
Current Rating: 3A Max
Material: PA66 Nylon
Connection Type: Screw-less waterproof connector
Operating Voltage: 300V
Assembly Method: Soldering or screw fitting
UV Resistance: Outdoor rated
Cable Jacket OD: 4.5-9.2 mm
Detailed Specifications
Parameter 2Pins 3Pins 4Pins 8Pins
Rated Voltage 300V 300V 300V 110V
Rated Current 1.6A 1.6A 1.6A 1.6A
Insulation Voltage 3KV 3KV 1KV 1KV
DC 500V Insulation Resistance 500MΩ 500MΩ 500MΩ 500MΩ
IP Code IP67 IP67 IP67 IP67
Cable Specifications ≤1.5mm² ≤1.5mm² ≤1.0mm² ≤0.75mm²
Assembly Cable Diameter 4.5-9.2mm 4.5-9.2mm 4.5-9.2mm 4.5-9.2mm
Product Features
M20 Waterproof Cable Connector Female Extension with IP44 Rating 16A Capacity and PA66 Nylon Material 0
This M20 Waterproof Cable Connector is designed for reliable performance in demanding environments. The 16A capacity and three straight female extension design provide flexibility for various applications including outdoor lighting installations and industrial machinery. Constructed with high-quality materials, it ensures long-lasting durability and protection against moisture and dust.
Technical Drawing
M20 Waterproof Cable Connector Female Extension with IP44 Rating 16A Capacity and PA66 Nylon Material 1
Frequently Asked Questions
What type of waterproof connectors do you have?
We offer a comprehensive range of waterproof connectors including private mold and customized solutions. Our product line includes P16 Self-Locking Injection Waterproof Connectors, Assembly waterproof connectors, Over-mold connectors, T-connectors, Y-connectors, and specialized connectors for livestock, poultry, new energy, and solar systems.
How to buy your products?
Contact our sales team online or by email. Please provide:
  • Current rating and number of contacts required
  • Assembly style preference
  • Cable wire gauge specifications
  • Cable length and shipping requirements
How to contact with you?
Please provide your email, phone number, Skype, or WhatsApp ID. With over 8 years of industry experience, our professional sales and R&D team can quickly address your requirements and provide effective solutions.
Can I get samples?
Yes, we provide samples with freight cost coverage. Please provide your courier account number and detailed shipping address for immediate sample dispatch.
Tags:

Waterproof Wire Nuts

Cable Waterproof Connector

Male Waterproof Wire Connector
