Y Type Waterproof Cable Connector IP67 Rated 500V with PA66 Nylon Material for Secure Connections

Brand Name: Cablein
Model Number: Y01
MOQ: 1PCS
Price: Price Can Contact With Our Sales
Packaging Details: High Quality export carton
Payment Terms: T/T,Western Union
Detail Information
Product Description
Detail Information
Place of Origin:
Shenzhen China
Certification:
CE, ROHS, TUV , ETL
Name:
LD20T Type Waterproof Cable Connector Three LD20 Aviation T Type Three One Tow Two
Material:
PA66 Nylon
Item Name:
Waterproof Cable Connector
Voltage:
500V
Waterproof:
IP68
Product Type:
Screw Waterproof Cable Connector
Assembly Wire:
Soldering
Connector Type:
Male/Female
Supply Ability:
50000pcs per day
Highlight:

Y Type Waterproof Cable Connector

,

Waterproof Cable Connector 500V

,

Parallel IP67 Nylon Cable Connector

Product Description
Y Type Waterproof Cable Connector 500V Parallel IP67 Nylon Cable Connector
Product Overview
The Diagonal Y Type Waterproof Cable Connector Series Parallel is engineered for superior performance in demanding environments. Constructed from high-quality PA66 nylon material with IP67 waterproof rating, this connector ensures reliable protection against moisture and environmental hazards.
Pin Configuration 2/3/4/8 Pins Male Female Connector
Current Rating 5A Max
Material PA66 Nylon
Connection Method Screw-less type waterproof connector
Operating Voltage 220V
Assembly Method Soldering or screw fitting
Outdoor UV Resistance Pass
Cable Jacket OD 4.5-9.2 mm
Y Type Waterproof Cable Connector IP67 Rated 500V with PA66 Nylon Material for Secure Connections 0
Product Features
This versatile connector supports both series and parallel connections, providing exceptional flexibility for various wiring configurations. The unique diagonal Y-type design combined with IP67 waterproof protection makes it ideal for industrial applications, outdoor installations, and any environment requiring reliable, waterproof cable connections.
Y Type Waterproof Cable Connector IP67 Rated 500V with PA66 Nylon Material for Secure Connections 1
Frequently Asked Questions
What types of waterproof connectors do you offer?
We provide a comprehensive range of waterproof connectors including P16 Self-Locking Injection Waterproof Connectors, Assembly waterproof connectors, Over-mold waterproof connectors, T-type connectors, Y-type customized connectors, and specialized connectors for livestock/poultry industries, new energy applications, and solar systems. Many of our connectors feature proprietary molds and custom designs.
How do I purchase your products?
Contact our sales team online or via email. Please provide the following specifications:
- Current rating and number of contacts required
- Preferred assembly style
- Cable wire gauge specifications
- Required cable length and shipping preferences
How can I contact you?
Please provide your email, phone number, Skype, or WhatsApp ID. Our team brings over 8 years of industry experience with professional sales and R&D support. We're committed to quickly understanding your requirements and providing effective solutions. Don't hesitate to reach out with any questions.
Professional Support: Our experienced team is ready to assist with technical specifications, custom requirements, and application guidance for all your waterproof connector needs.
