M20 Panel RJ45 Waterproof Signal Connector with IP67 Rating and PA66 Nylon Material for 1000MHz Transmission

Brand Name: Cablein
Model Number: CB-M20-FBF01-X
MOQ: 1PCS
Price: Price Can Contact With Our Sales
Packaging Details: High Quality export carton
Payment Terms: T/T,Western Union
Detail Information
Product Description
Detail Information
Place of Origin:
Shenzhen China
Certification:
CE, ROHS, TUV , ETL, CB, SAA
Name:
M20 Panel RJ45 Waterproof Sgnal Connector 180 Degree Crystal Aviation Plug
Metal:
Gilded Brass
Material:
PA66 Nylon
Insertion Life:
1000 Times
Voltage:
125V
Waterproof:
IP67
Highlight:

RJ45 Cable Connector Waterproof

,

M20 Signal Cable Connector

,

RJ45 Signal Cable Connector

Product Description
M20 Panel RJ45 Signal Cable Connector Waterproof 180 Degree Crystal Aviation Plug
Product Specifications
Pin Configuration RJ45 Connector
Current Rating 1.5A Max
Material PA66 Nylon
Transmission Speed CAT.5e (1000MHz)
Operating Voltage 125V
Assembly Method Soldering or screw fitting
Outdoor UV Resistance Pass
Panel Thickness Max 2.0 mm
IP Rating IP67
Key Features
  • Advanced IP67 self-locking connector structure
  • Multiple pin configurations available: 2 to 32 pins
  • Flexible connection methods: soldering or screw terminal
  • Versatile assembly options: cable-to-cable, male and female without cable
  • Push-pull locking type connection
  • Certifications: UL, TUV, CE, ROHS, CQC
Application Industries
Stage Equipment
Smart Grid
LED Lighting
Solar Energy Equipment
Ship Equipment
Agriculture
Electric Power Equipment
Vehicle Equipment
Ebike/Motorcycle
Communications Equipment
Heavy Machinery
Transportation
Product Drawing
M20 Panel RJ45 Waterproof Signal Connector with IP67 Rating and PA66 Nylon Material for 1000MHz Transmission 0
The M20 Panel RJ45 Waterproof Signal Connector offers reliable performance in demanding environments. Its IP67 waterproof rating ensures protection against dust and moisture, making it suitable for various industrial applications. The connector supports high-speed data transmission up to 1000MHz and features a durable PA66 nylon construction with excellent UV resistance for outdoor use.
Frequently Asked Questions
How to buy your products?
Contact our sales team online or by email. Please provide the following information:
  • Current rating and number of contacts required
  • Assembly style preference
  • Cable wire gauge specifications
  • Cable length and shipping method
Can I get samples?
Yes, we are pleased to offer samples. You only need to pay the freight cost. Please provide your courier account number and detailed shipping address, and we will dispatch the sample immediately.
