M25 3-Core Front Waterproof Panel Mount Connector Female with 400V Operating Voltage and Screw Threaded Connection for Photovoltaic Micro Inverters

Brand Name:	Cablein
Model Number:	CB-M25-3P
MOQ:	1PCS
Price:	Price Can Contact With Our Sales
Packaging Details:	High Quality export carton
Payment Terms:	T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen China

Certification:

CE, ROHS, TUV , ETL

Connector Size:

M25-3-Core Front Waterproof Panel Mount Connector Female For Photovoltaic Micro Inverters

Connector Style:

Straight

Connection Mode:

Screw Threaded

Connector Locking System:

Screw

Durability:

≥1000 Times

Industrial Electronics:

Accessories

Cable Range:

6-10mm

Connector Type:

Push Locking

Highlight:

M25 Waterproof Panel Mount Connector

Waterproof Panel Mount Connector Female

Product Description

M25 3-Core Front Waterproof Panel Mount Connector Female

Product Overview

Specialized female connector designed for photovoltaic micro inverters, providing reliable watertight connections for solar energy systems.

Key Specifications

Pin Options: 2/3/4/5/7/9/12 Male Female Connector

Current Rating: 10A Maximum

Material: PA66 Nylon

Connection Type: Screw-less waterproof connector

Operating Voltage: 400V

Wire Assembly: Soldering or screw fitting

UV Resistance: Outdoor rated

Cable Jacket OD: 4-9mm

Technical Specifications

Part No.	CB-LP25-2P	CB-LP25-3P	CB-LP25-4P	CB-LP25-5P	CB-LP25-7P	CB-LP25-9P
Pins	2 Pin	3 Pin	4 Pin	5 Pin	7 Pin	9 Pin
Wire Connection - Bonding	✓	✓	✓	✓	✓	✓
Wire Connection - Locking	✓	✓	✓	✓	*	*
Contact Member - Bonding Wire	φ2.7*2	φ2.7*3	φ2.7*4	φ1.8*5	φ1.8*7	φ1.0*9
Contact Member - Locking Wire	φ2.4*2	φ2.4*3	φ2.4*4	φ1.8*5	*	*
Applicable Wire Gauge	1.5mm² / 16AWG	0.5mm² / 20AWG	0.5mm² / 20AWG
Rated Current	15A	5A	5A
Rated Voltage	400V AC	250V AC	250V AC

Performance Characteristics

Insulation Voltage: 2000V AC / 1500V AC

Contact Impedance: < 3 mΩ / < 5 mΩ

Temperature Rise: Varies by current rating and configuration

Insulation Resistance: ≥ 1000 MΩ

Mechanical Life: ≥ 1900 Cycles

Ambient Temperature: -40°C to +85°C

High Temperature Aging: 85°C / 168 hours

Product Features

The M25-3-Core Front Waterproof Panel Mount Connector Female is engineered specifically for photovoltaic micro inverters, delivering reliable and watertight connections that ensure the safety and efficiency of solar energy systems.

Secure female design prevents loose connections and power loss

Waterproof construction protects against moisture and environmental factors

Enhanced durability and longevity for photovoltaic applications

Guarantees stable power output and optimal system performance

Essential component for resilient solar energy conversion systems

Applications

Ideal for photovoltaic micro inverters and solar energy systems requiring reliable, waterproof electrical connections in outdoor environments.

Frequently Asked Questions

What type of waterproof connectors do you have?

We offer a comprehensive range of waterproof connectors including private mold designs and custom solutions. Our portfolio includes P16 Self-Locking Injection Waterproof Connectors, Assembly waterproof connectors, Over-mold connectors, T-connectors, Y-customized connectors, and specialized solutions for livestock, poultry, and new energy applications including solar systems.

How to buy your products?

Contact our sales team online or by email with the following information:

Current rating and number of contacts required

Preferred assembly style

Cable wire gauge specifications

Cable length and shipping preferences

How to contact with you?

Please provide your email, phone number, Skype, or WhatsApp ID. Our professional sales and R&D team with over 8 years of industry experience is ready to address your requirements and provide timely solutions.

Can I get samples?

Yes, we are pleased to provide samples. You only need to cover the freight cost. Please provide your courier account number and detailed shipping address for immediate sample dispatch.

Contact Information: Please reach out to our sales team for pricing, technical specifications, and custom requirements.
