M20 Front 3-Core Screw Threaded UV Resistant Waterproof Panel Mount Connector for Micro Solar Inverter

Brand Name: Cablein
Model Number: CB-M20-3P
MOQ: 1PCS
Price: Price Can Contact With Our Sales
Packaging Details: High Quality export carton
Payment Terms: T/T,Western Union
Detail Information
Product Description
Detail Information
Place of Origin:
Shenzhen China
Certification:
CE, ROHS, TUV , ETL
Connector Size:
M20 Front 3-Core Waterproof Panel Mount Connector Male Head Of Micro Solar Inverter
Connector Style:
Straight
Connection Mode:
Screw Threaded
Connector Locking System:
Screw
Durability:
≥1000 Times
Industrial Electronics:
Accessories
Cable Range:
6-10mm
Connector Type:
Push Locking
Highlight:

Male Waterproof Panel Mount Connector

,

Three Core Waterproof Panel Mount Connector

Product Description
M20 Front Three Core Male Waterproof Panel Mount Connector For Micro Solar Inverter
Product Specifications
Pin Configuration: 2/3/4/5/7/9/12 Male/Female Connector
Current Rating: 10A Maximum
Material: PA66 Nylon
Connection Method: Screw-less type waterproof connector
Operating Voltage: 400V
Assembly Wire: Soldering or screw fitting
Outdoor UV Resistance: Certified Pass
Cable Jacket OD: 4-9mm
Technical Datasheet
Part No. CB-LP20-2P CB-LP20-3P CB-LP20-4P CB-LP20-5P CB-LP20-7P CB-LP20-9P
Pins 2 Pin 3 Pin 4 Pin 5 Pin 7 Pin 9 Pin
Wire Connection - Bonding ✓ ✓ ✓ ✓ ✓ ✓
Wire Connection - Locking ✓ ✓ ✓ ✓ * *
Contact Member - Bonding Wire φ2.7*2 φ2.7*3 φ2.7*4 φ1.8*5 φ1.8*7 φ1.0*9
Contact Member - Locking Wire φ2.4*2 φ2.4*3 φ2.4*4 φ1.8*5 * *
Applicable Wire Gauge 1.5mm² / 16AWG 0.5mm² / 20AWG 0.5mm² / 20AWG 0.5mm² / 20AWG 0.5mm² / 20AWG 0.5mm² / 20AWG
Rated Current 15A 5A 5A 5A 5A 5A
Rated Voltage 400V AC 250V AC 250V AC 250V AC 250V AC 250V AC
Additional Specifications:
  • Insulation Voltage: 2000V AC / 1500V AC
  • Contact Impedance: < 3 mΩ / < 5 mΩ
  • Temperature Rise: Varies by model and current rating
  • Insulation Resistance: ≥ 1000 MΩ
  • Mechanical Life: ≥ 1900 Cycles
  • Ambient Temperature: -40°C to +85°C
  • High Temperature Aging: 85°C / 168 hours
Product Features & Advantages
M20 Front 3-Core Screw Threaded UV Resistant Waterproof Panel Mount Connector for Micro Solar Inverter 0

The M20 Front 3-Core Waterproof Panel Mount Connector represents advanced engineering for solar energy systems. Designed specifically for micro solar inverters, this connector delivers exceptional durability and performance in demanding outdoor environments.

  • Superior waterproof protection for harsh outdoor conditions
  • Three-core configuration for efficient power transmission
  • Maximizes micro solar inverter output performance
  • Simplified installation and maintenance processes
  • Reduces system downtime and enhances overall efficiency
  • Suitable for both residential and commercial solar applications
Applications
M20 Front 3-Core Screw Threaded UV Resistant Waterproof Panel Mount Connector for Micro Solar Inverter 1

This connector is specifically designed for micro solar inverter systems and is widely used in various solar energy applications where reliable, waterproof connections are essential for optimal performance.
