IP67 Waterproof Circular Connector with Self-Locking Butt Type and 500V Operating Voltage

Brand Name: Cablein
Model Number: CB-P16-FDF01-3P-X
MOQ: 1PCS
Price: Price Can Contact With Our Sales
Packaging Details: High Quality export carton
Payment Terms: T/T,Western Union
Detail Information
Product Description
Detail Information
Place of Origin:
Shenzhen China
Certification:
CE, ROHS, TUV , ETL
Conenction Way:
Self-locking Butt Type
Operating Voltage:
500V
Product Category:
Waterproof Circular Connector
Voltage:
500V
Metal:
Gilded Brass
Assembly Wire:
Soldering Or Screw Fitting
Waterproof:
IP67
Out Door UV Resistance:
Pass
Highlight:

Sealed Circular Power Cable Connector

,

Circular Power Cable Connector Waterproof

Product Description
Sealed Circular Power Cable Connector
Waterproof self-locking butt type connection with IP67 rating for harsh environments
Product Overview
The Waterproof Circular Connector features a cable jacket OD of 4.5-9.2 mm², providing compatibility with various cable types for maximum versatility. With an IP67 rating, it is dust-tight and can withstand water immersion up to 1 meter deep for 30 minutes, making it ideal for wet and damp environments.
The self-locking butt design ensures secure connections that resist vibration and movement. Built for durability, the connector offers an insertion life of up to 1000 cycles without losing functionality. Outdoor UV resistance protects against sunlight degradation, essential for prolonged outdoor exposure.
Key Features
  • Material: PA6 Nylon construction
  • Outdoor UV Resistance: Certified pass
  • Connection Type: Self-locking butt design
  • Operating Voltage: 500V rating
  • Waterproof Coupler with IP67 protection
  • Water-resistant circular connector
  • Current Rating: 15A maximum
Technical Specifications
Product Name IP67 Self-Locking Butt Waterproof Circular Connector with 4 Pin Male Female Connection
Pin Configuration 4 Pin Male Female Connector
Material PA6 Nylon
Metal Components Gilded Brass
Operating Voltage 500V
Current Rating 15A Max
Assembly Method Soldering or screw fitting
Insertion Life 1000 Cycles
Applications
The Cablein Waterproof Circular Connector CB-P16-FDF01-3P-X is a splashproof, submersible connector ideal for various industries and environments:
  • Communications equipment and systems
  • Product coding machines and inventory systems
  • Inkjet systems and industrial printing equipment
  • Solar power systems and renewable energy
  • Electric power equipment
  • Laboratory forensic and pathology equipment
  • Heavy machinery and industrial equipment
Technical Support & Services
Our comprehensive support package includes expert technical assistance, customized solutions, installation services, and regular maintenance. Our team provides training and ongoing support to ensure optimal product performance and integration into your existing systems.
Packaging & Shipping
Packaging Details
  • Individual polybag packaging per connector
  • 10 connectors per small box
  • 100 small boxes per master carton
  • Master carton dimensions: 50cm x 40cm x 30cm
Shipping Information
Shipping Method: UPS Ground
Shipping Time: 3-5 business days
Shipping Cost: Calculated at checkout based on weight and destination
Frequently Asked Questions
What is the brand name of the waterproof circular connector?
The brand name is Cablein.
What is the model number?
The model number is CB-P16-FDF01-3P-X.
What certifications does the connector have?
Certified by CE, ROHS, TUV, and ETL.
What is the minimum order quantity?
Minimum order quantity is 1 piece.
What are the payment terms?
Payment terms are T/T and Western Union. Contact our sales team for pricing.
What is the delivery time?
Delivery time is 5-8 working days.
What are the packaging details?
Packaged in high-quality export carton.
IP67 Waterproof Circular Connector with Self-Locking Butt Type and 500V Operating Voltage 0 IP67 Waterproof Circular Connector with Self-Locking Butt Type and 500V Operating Voltage 1
Tags:

Water Resistant Circular Connector

Male And Female Connectors

Circular Cable Connectors
