IP68 Waterproof 20A 4-Pin LP20 Power Connector Solder Type

Brand Name:	Cablein
MOQ:	100PCS
Price:	The price ranges from $1 to $4 USD per pieces
Packaging Details:	High Quality export carton
Payment Terms:	T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen China

Certification:

CE, ROHS, TUV , ETL

Temperature Range:

-20~+80 Degrees/-40~+105 Degrees

Keywords:

Power Cable Connector

Cable Diameter:

4-8mm

Metal:

Gilded Brass

Colour:

Black

Termination Style:

Solder

Connector Type:

Circular

Waterproof Level:

IP68

Supply Ability:

Sufficient supply capacity

Highlight:

IP68 waterproof LP20 power connector

4-pin solder type power connector

waterproof circular connector 20A

Product Description

IP67 Panel Mount Power Connector, 20A 4-Pin LP20 Series, Metal-Nylon Housing, Solder Type

Product Specifications

Attribute	Value
Temperature Range	-20~+80°C/-40~+105°C
Cable Diameter	4-8mm
Metal	Gilded brass
Colour	Black
Termination Style	Solder
Connector Type	Circular
Waterproof Level	IP68

Key Features

Pin: 4 Pin
Current Rating: 20A Max
Material: Metal+plastic construction
Connection Method: Push-button snap fastener
Operating Voltage: 500V Max
Assembly Wire: IP-Rated Locking Gland
Mounting Type: Panel Mounting
UV Resistance: Passed outdoor testing
Cable Jacket OD: 2.5-4 mm²

Technical Specifications

Pins Number	2Pins	3Pins	4Pins
Rated Voltage	500V		250V
Rated Current	20A	10A	5A
Insulation voltage	2.5KV	1.5KV
IP CODE	IP68
Cable Jacket OD	Standard Power: ⌀8-12mm Standard Signal: ⌀5-6.5mm Other: ⌀5-9mm
Assembly cable diameter	2.4-4mm²/14-12AWG \| 1-1.5mm²/18-16AWG \| 0.34-0.75mm²/22-20AWG
Ambient temperature	-40℃~+80℃

Product Advantages

Material & Performance: High-performance PBT engineering plastic housing with stable electrical properties, excellent heat and corrosion resistance. Gold-plated conductive components ensure superior conductivity.
Secure Locking Mechanism: Push-to-lock snap-fit design for secure mating and smooth insertion/removal.
Waterproof Design: Standard IP67 rating (IP68 optional) provides precise waterproof protection.
Certifications & Compliance: Complies with TUV, ISO, CE, and RoHS certifications.

Product Images

Application Industries

Automation Equipment

LED Lighting

Security Equipment

Telecommunication Equipment

New Energy

Electronic Devices

Technical Drawings

Frequently Asked Questions

What is the primary application environment for this LP20 Series 20A connector? Is it suitable for outdoor use?

Absolutely. This connector is specifically engineered for harsh environments. Its IP67 rating guarantees complete protection against dust ingress and allows it to be submerged in water up to 1 meter deep for 30 minutes. This makes it an ideal solution for outdoor applications, industrial machinery, marine equipment, and any setting exposed to moisture, dust, or occasional washdowns. The combination of a metal shell and nylon base provides excellent resistance to corrosion, impact, and UV exposure.

Why does the connector use a combination of Metal and Nylon in its housing? What are the benefits?

The hybrid Metal-Nylon Housing design offers the best of both materials:

Metal Shell: Provides superior mechanical strength, durability, and shielding against electromagnetic interference (EMI), protecting the connection from external signals and vice versa.
Nylon Base: Offers high impact resistance, excellent chemical and corrosion resistance, and electrical insulation. It is also lighter in weight and helps reduce overall costs without compromising performance.

This combination ensures a robust, reliable, and long-lasting connector that can withstand demanding conditions.

The product is listed as "Solder Type." What is the advantage of this termination method, and are other termination options available?

The Solder Type termination provides a permanent, gas-tight, and highly reliable electrical connection. It is renowned for its superior mechanical strength and excellent current-carrying capability, making it ideal for high-vibration environments and applications where a secure, long-term connection is critical. While this specific model is a solder version, the LP20 series may offer other termination styles like screw terminals or crimp contacts. Please check our full product catalog or contact our sales team to inquire about alternative termination options for your specific needs.
