IP68 Waterproof 2-Port Split-Type Junction Box

Brand Name:	Cablein
MOQ:	100PCS
Price:	The price ranges from $1 to $4 USD per pieces
Packaging Details:	High Quality export carton
Payment Terms:	T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen China

Certification:

CE, ROHS, TUV , ETL

Installation Style:

AC/DC

Protection Grade:

IP65 - IP68

Color:

Black Yellow

Operating Temperature:

-40°C To 105°C

Mechanical Life:

1500 Mating Cycles

Cable Length:

Per Your Requirement

Current Rating:

40A

Certifications:

UL/CE/RoHS

Highlight:

IP68 waterproof junction box

split-type waterproof connector

2-port waterproof junction box

Product Description

IP68 Waterproof 2-Port Split-Type Junction Box

Specifications

Connection Type: Screw-Type

Type: 1-in-2-out

Material: Plastic

Applicable Wire Gauge: 0.5mm²-6mm²

Outer Diameter (OD): 5-9mm 9-12mm 10-14mm

P/N :CB-2068L-3T

Datasheet

Parameter	Specification
Product Name	3T/4T Junction Box
Wiring Range	0.5 - 6 mm²
Rated Current	40000mA
Operating Voltage	0.45KV
Ingress Protection (IP) Rating	IP68
Ambient Temperature	-40℃ ~ +105℃
Cable Diameter (OD)	5 - 9 mm, 9 - 12 mm,10-14mm

Advantages:

1. Unmatched IP68 Protection for Total Peace of Mind

Engineered with a complete IP68 rating, this junction box offers absolute defense against dust, dirt, and continuous submersion in water, ensuring reliable performance in the most demanding outdoor, industrial, or underground environments.
2. Effortless Installation and Maintenance with Split-Type Design

The innovative separate base and cover design provides full, tool-free access to terminal connections. This drastically simplifies the initial wiring process and makes any future inspections or modifications quick and hassle-free.
3. Efficient and Organized 2-Port Cable Distribution

The versatile 1-in-2-out design allows a single power or signal source to be cleanly split into two separate outputs. This enables organized cable management for multiple devices, saving space and reducing clutter.
4. Rugged and Durable Construction for Longevity

Built from high-quality, corrosion-resistant materials like PC/ABS plastic, the enclosure is designed to withstand physical impact, UV radiation, and extreme temperatures, guaranteeing long-term durability and operational safety.

Product Images

FAQ

1. Q: What does IP68 mean?

A: It means the box is totally dust-tight and can be continuously submerged in water deeper than 1 meter.

2. Q: What is it used for?

A: It's used to protect electrical wire connections and split one cable into two, outdoors or in wet locations.

3. Q: How do I install it?

A: It's easy. Separate the base from the cover, connect the wires to the terminals inside, then screw the cover back on.

4. Q: What size cable fits?

A: It fits standard cables with a diameter between 5mm and 12mm.

5. Q: Is it really for outdoor use?

A: Yes. Its IP68 rating and strong plastic material are made for outdoor, industrial, or underground use.
