M25 Feed-Through Cross-Type Waterproof Connector
2. Available in IP67 and IP68 waterproof ratings.
3. Cross-shaped four-port design with main cable passing straight through and two branches exiting from both sides.
4. Cable and connector are factory overmolded into one piece, ready for use out of the box.
5. CE and TUV certified, compliant with RoHS standards.
6. Operating temperature range from -40℃ to 105℃ for various industrial environments.
7. Technical consultation and quick sampling services are available.
8. Custom options include pin count, individual branch cable lengths, and exit orientations.
M25 Feed-Through Cross-Type Waterproof Connector - Industrial Cross Junction Solution
Cablein Technology's M25 Feed-Through Cross-Type Waterproof Connector delivers industrial-grade reliability through its cross-shaped four-port design. Built with PA66 nylon lodging and gold-plated copper combination contacts, this connector accomplishes IP67/IP68 waterproof evaluations and works dependably over -40℃ to +105℃. Appraised at 250V/16A with 3-pole setup, it highlights plant overmolding that coordinating cable and connector into one fixed unit. Supporting cable breadths from 5-14mm and wire segments of 0.5-2.5mm², this CE and TUV certified arrangement kills numerous intersection boxes through its ceaseless primary cable structure, empowering proficient multi-point control conveyance for requesting environments.
What Makes This Cross-Type Waterproof Connector Different?
Your establishments require more than fundamental weatherproofing. They require cleverly plan that disentangles complex wiring networks.
This feed-through connector addresses your genuine challenges: cable weariness at basic intersection focuses, time-consuming field establishments, and keeping up natural judgment over different association points.
The cross-shaped engineering lets your primary cable pass straight through whereas branching control or signals to both sides. You dispense with pointless intersection boxes and decrease potential disappointment focuses in your system.
Think of it as a activity crossing point for your electrical infrastructure—four bearings overseen through one vigorous, pre-sealed association point.
Technical Foundation You Can Rely On
Material Engineering
The PA66 nylon housing resists UV degradation and chemical exposure. Gold-plated contacts prevent corrosion in humid conditions. Silicone sealing rings maintain flexibility across extreme temperature swings.
Electrical Performance
You get consistent 250V/16A capacity through 3-pole configuration. The wire section accommodates 0.5-2.5mm² cables, giving you flexibility for various wire gauges.
Environmental Protection
IP67 and IP68 ratings mean your connections stay protected during dust storms, heavy rain, or temporary submersion. The operating range of -40℃ to +105℃ covers arctic cold to desert heat.
Real-World Applications Where Performance Matters
Street Lighting Networks
Your lighting infrastructure needs fewer connection points and faster installation. This M25 Feed-Through Cross-Type Waterproof Connector powers multiple fixtures from a single trunk line. Each branch connects individual poles without interrupting the main power flow.
Security Camera Systems
Install cameras along building perimeters with minimal wiring complexity. The cross design lets you tap power and data from your main run without creating vulnerable splice points.
Industrial Production Lines
Manufacturing equipment requires power distribution across conveyor systems and workstations. The feed-through structure supports equipment on both sides of your main power corridor.
Outdoor LED Displays
Large-format displays need reliable connections that withstand weather exposure. The one-piece overmolding protects every cable entry point without field-applied sealants.
Installation Advantages That Save Time
Traditional junction methods require you to strip cables, apply sealants, and hope your field work holds up. Not here.
Factory-sealed integration means every cable exits through professionally molded housings. You don't handle gaskets or worry about proper seal compression.
Continuous trunk design allows current to flow uninterrupted. Your branch connections don't compromise the main power delivery.
Reduced components translate directly to fewer inventory items and simpler maintenance schedules.
Customization Options for Your Specific Needs
Your projects don't fit standard templates. We understand that.
Pin count variations accommodate different signal or power requirements beyond the standard 3-pole configuration.
Individual branch lengths can be specified for each exit point. Your left branch might need 2 meters while the right needs 5 meters.
Cable diameter options span 5-9mm, 9-12mm, and 10-14mm ranges to match your existing wire infrastructure.
Exit orientations can be adjusted during manufacturing to align with your enclosure design or mounting constraints.
Quality Standards Behind Every Unit
CE and TUV certifications validate compliance with European safety standards. RoHS compliance ensures you're not introducing hazardous substances into your equipment.
Each connector undergoes hydrostatic pressure testing to verify waterproof integrity. Insulation resistance tests prevent electrical leakage under full load conditions.
Salt spray testing confirms corrosion resistance for coastal installations. Thermal cycling verifies seal integrity through repeated temperature extremes.
You receive connectors that have passed mechanical pull-out testing—ensuring cable retention exceeds 100N force.
Frequently Asked Questions
Q: Can I utilize this connector for both AC and DC power?
A: Yes, the 250V/16A rating applies to both AC mains control and DC frameworks. Fair remain inside the voltage and current details for your application.
Q: What happens if my cable breadth falls between the standard ranges?
A: We give measuring direction amid determination. For non-standard cables, custom fixing embeds can oblige your correct breadth whereas keeping up IP68 integrity.
Q: How does the feed-through plan join to my board or enclosure?
A: The M25 strung lodging mounts through your board opening. A locknut and compression O-ring seal against the walled in area surface, making a watertight barrier.
Q: Is the connector safe to cleaning chemicals utilized in nourishment processing?
A: When indicated with suitable seal materials, it stands up to common mechanical cleansers and sanitizers. Affirm your particular chemicals amid consultation.
Q: Can I indicate diverse wire gages for each branch?
A: Yes, custom setups permit distinctive wire areas per department. This underpins applications where your fundamental trunk carries higher current than person branches.
Q: What establishment instruments do I need?
A: Fundamental hand instruments for board mounting. Since cables are pre-attached and fixed, you maintain a strategic distance from specialized pleating or fixing equipment.
Start Your Next Project Right
Ready to simplify your wiring architecture? Contact us at nick@cableinco.com to discuss your M25 Feed-Through Cross-Type Waterproof Connector requirements, obtain technical drawings, request samples, or confirm compatibility with your existing systems. Bookmark this page for future reference.
