LP24 12-Pin High-Density Circular Connector

LP24 12-Pin High-Density Circular Connector – 10A Twelve-Pole Connection with IP68 Sealing

Twelve wires. One plug. The LP24 12-Pin High-Density Circular Connector handles 10A per contact at 250V across twelve separate poles, sealed to IP68 and wired with solder terminals. That density is the point — control cabinets running twelve separate signal lines don't have room for two connectors. This one keeps it in a single shell.

LP24 12-Pin High-Density Circular Connector – The Density Problem Twelve-Pole Equipment Runs Into

Twelve poles is past the point where a single shell feels natural. It's the kind of wiring where you'd normally split into two connectors and double the panel space. The LP24 12-Pin High-Density Circular Connector skips that step. Twelve soldered joints hold each line tight, and the keyway keeps orientation consistent so you're not guessing which pin is which. Cable entry takes 1.5mm² (16 AWG) wire with a 14mm outer diameter.

Twelve contacts at 10A each. That's not a power connector — it's a high-density signal run. We've seen these end up on multi-axis control panels and instrumentation racks where twelve separate lines all have to reach the same enclosure.

Sealed Where It Matters

The housing is metal on the coupling thread — that's the part that takes the beating when someone cranks it too hard in the field — and plastic everywhere else to keep it light. IP68 sealing, so rain, washdown, and wet factory floors aren't a problem. Tested at 2 meters for 24 hours. Nothing fancy. It just holds.

Technical Specifications at a Glance

Where This 12-Pin Connector Actually Gets Used

Twelve-line runs in tight panels. Multi-axis control panels. Instrumentation racks. Multi-sensor automation cells. Industrial camera arrays. Test and measurement equipment. Anywhere you've got twelve separate lines running into equipment that gets wet — and that's where the LP24 12-Pin High-Density Circular Connector ends up.

Each production batch goes through a phase-to-phase insulation test, plus the usual dielectric and waterproof checks. Twelve poles means more paths for a fault to hide, so the testing takes longer on this one than on our 2-pin and 3-pin versions. Worth it.

Quality Control and Certifications

The LP24 series carries TUV, CE, and RoHS. We run ISO9001:2015, so material sourcing is consistent and production records are traceable. And the quality system actually gets audited — not just claimed.

Quick Questions We Get Asked

Q: Is this for power or signal?

A: Twelve poles at 10A is signal or control. For higher current per line, the 2-pin and 3-pin LP24 versions are the better fit.

Q: How do I keep twelve lines straight?

A: Label everything before you start. Use the keyway on the housing to orient the connector the same way every time. Twelve poles is where mix-ups happen most.

Q: What cable size does it take?

A: 1.5mm² (16 AWG) with a 14mm outer diameter. Signal and control class.

Q: Can it stay submerged?

A: Yes. IP68 covers continuous immersion. We test at 2 meters for 24 hours.

Want to Know More?

For specs, custom pin counts, or samples of the LP24 12-Pin High-Density Circular Connector, email nick@cableinco.com. Tell us your signal layout — we'll confirm the build.
