LP24 2-Pin Screw Lock Waterproof Connector

LP24 2-Pin Screw Lock Waterproof Connector – 35A High-Current Connection with Tool-Free Wiring

High current and field wiring don't always play nice together — we've been building connectors long enough to know that. The LP24 2-Pin Screw Lock waterproof connector is the answer to that problem. 35A per contact. 500V. Screw terminals you tighten with a screwdriver. And IP68 sealing that doesn't mind getting wet. Two pins, one job — push serious power through a connection that stays sealed and stays tight.

LP24 2-Pin Screw Lock Waterproof Connector – Built for High-Current, Wet Environments

Most 2-pin connectors top out at 10A or 20A. This one handles 35A. That's the difference between powering a sensor and powering a motor, a pump, or a heating element. The screw-lock terminals are a deliberate choice — soldered joints work, but they need an iron on site. Screw terminals just need a screwdriver. For equipment that needs to be wired up in the field, that matters.

The IP68 rating means this connector can sit in standing water or take a pressure wash without letting moisture in. We test at 2 meters for 24 hours. Cable entry handles 6mm² (10 AWG) wire with a 14mm outer diameter — thick cable for serious current.

Why Screw Lock, Not Crimp

Crimped connections? Fast in a factory. Out in the field, though, you need a calibrated tool and someone who knows how to use it. Screw-lock skips all that. Tighten the screw, it stays tight. And the cable gland holds the cable on its own, separate from the contacts — so when something pulls, the terminals don't feel it.

The housing mixes metal and plastic — metal on the coupling thread where the wear happens, plastic elsewhere to keep it light. IP68 sealing, so marine use, outdoor power distribution, industrial washdown — all fine.

Technical Specifications at a Glance

​​​​​​​Where This High-Current Connector Actually Gets Used

This connector shows up where 35A meets water. Marine shore power. Outdoor EV charging equipment. Industrial motor junction boxes. Pump stations. Construction site power distribution. Agricultural irrigation controls. Anywhere you need to push serious current through a connection that gets wet and gets wired on site.

We test every batch for dielectric strength and waterproof performance. The screw terminals get torque-checked, not just eyeballed. It adds time, but it saves callbacks.

Quality Control and Certifications

The LP24 series carries TUV, CE, and RoHS certifications, and we operate under ISO9001:2015. Consistent material sourcing, traceable production records, and a quality system that gets audited — not just claimed.

Quick Questions We Get Asked

Q: Why screw lock instead of solder?

A: Field wiring. Not everyone carries a soldering iron to the job site. Screw terminals let you terminate 6mm² cable with a screwdriver, and the clamp holds it tight under vibration.

Q: What cable size does it accept?

A: 6mm² (10 AWG) with a 14mm outer diameter. That's power-class cable, sized for the 35A rating.

Q: Is IP68 enough for continuous submersion?

A: Yes. IP68 means it's rated for continuous immersion under specified conditions. We test at 2 meters for 24 hours.

Q: Can I re-terminate in the field if needed?

A: Yes — loosen the screw, adjust, re-tighten. No wasted connector, no soldering iron needed.

Ready to Get Started?

For specs, custom pin configurations, or samples of the LP24 2-Pin Screw Lock Waterproof Connector, email nick@cableinco.com. Tell us your current and cable size — we'll confirm the right build.
