LP20 7-Pin Plastic Metal Waterproof Crimp Plug
2.7 pins give you a ton of room for mixed signals and control lines in one cable, so you're not pulling extra runs.
3.Rated at 10A/250V for 1-1.5 mm² wire. Not for massive power, but perfect for control circuits.
4.Metal takes the hits and sheds heat, while plastic keeps the whole plug light and easy to bend around corners.
5.IP67 seal locks out water and dust for 8-12mm cables—hose it off or leave it in the rain, it won't care.
6.Once that screw bites into the wire, normal machine vibration won't shake it loose.
7.From Cablein Technology—standard stock ready to ship, with custom pin layouts if your project needs something specific.
8.Part Number：LP-20-C07PE-21-001 LP-20-J07PP-21-001 LP-20-J07SX-21-101 LP-20-J07SX-21-401.
LP20 7-Pin Plastic Metal Waterproof Crimp Plug——Fast, Solder-Free Wiring for Multi-Channel Control Circuits
Running 7 separate control lines out to a machine and dreading the soldering iron? The LP20 7-Pin Plastic Metal Waterproof Crimp Plug from Cablein Technology is built for this exact job. You just strip the wire, shove it into the terminal, and crank the screw down tight. That gives you a solid 10A/250V connection. And because the seal fits 8 to 12 mm cables, it’s IP67 rated, so water and dust stay outside.
Why Choose Our 7-Pin Plastic Metal Waterproof Crimp Plug?
Screw Terminals for On-Site Speed
No soldering, no crimping tools. Just a screwdriver. If you're wiring up multiple machines on site, this saves you a ton of time. Once you crank that screw tight, the terminal bites right into the wire. It’s not going anywhere—normal vibration won't shake it loose.
Metal and Plastic Work Together
Metal does the heavy lifting—it takes the impacts and handles the heat. The plastic is just there to keep the weight down so the cable isn't a pain to bend. And that mix actually cuts down on electrical noise, which is a huge relief when you're cramming it into a packed control cabinet.
IP67 Sealing for 8-12mm Cables
The silicone ring is built to fit thicker cables. Once you screw the connector down tight, that ring squishes right into place. You can blast it with a hose or leave it out in the rain—nothing's getting in.
Handles 10A at 250V
Rated at 10A and 250V, it takes 1-1.5 mm² wire. It's not built for massive power runs, but it's perfect for control circuits and complex signal bundles.
Technical Specifications
|
Connector Series |
LP20 |
Rated Voltage |
250V |
|
Number of Pins |
7 |
Withstand Voltage |
1500V |
|
Termination Type |
Screw |
Ingress Protection |
IP67 |
|
Installation Style |
Cable-to-Cable |
Cable Diameter Range |
8–12 mm |
|
Housing Material |
Plastic + Metal |
Operating Temperature |
-40°C to +80°C |
|
Rated Current |
10A |
Compatible Wire Gauge |
1–1.5 mm² (18-16AWG) |
Where This 7-Pin Connector Earns Its Keep
Complex Control Panels
Got a mess of control lines to run between cabinets? 7 pins means you're pulling fewer cables. And since you don't have to drag out a soldering iron, fixing a bad wire is a five-minute job instead of an all-day headache.
Stage and Event Control
Lighting desks and controllers need multiple channels. If a wire gets yanked during setup, you just loosen the screw and swap it—no need to drag out a soldering station.
Agricultural Irrigation Systems
Outdoor irrigation boxes are always getting soaked. But 10 amps is more than enough to drive those valve controllers and sensors. And since it's threaded, the connection stays tight even when the whole panel is vibrating.
Marine Electronics Panels
Salt spray just destroys cheap plastic plugs. That’s why the metal body on this one matters—it actually holds up against corrosion. And with that IP67 seal, moisture won't get inside and mess up your control signals.
Food Processing Control Boxes
Food plants get hosed down constantly. Standard plastic plugs just crack and fall apart under that kind of chemical abuse. The metal parts on this one actually survive it, which means you aren't constantly swapping them out.
Quality Control at Cablein Technology
Before anything leaves our factory, it goes through strict ISO9001:2015 checks. We dunk them in water to confirm the IP67 seal holds at the 8-12mm cable range. We test the 10A/250V rating and 1500V withstand voltage. We also check the screw threads to make sure they don't strip. It means the LP20 7-Pin Plastic Metal Waterproof Crimp Plug you receive is ready for the field.
Common Questions
Q: Can I get this connector with a different number of pins?
A: Yes, we make them in 2, 3, 4, 5, 7, 9, and 12 pin versions. Tell us what your application needs.
Q: Is this for high-power loads?
A: No. The 7-pin version is rated at 10A/250V, which is ideal for mixed power and signal circuits. If you need higher current, check out our 2-pin or 3-pin models.
Q: Will my cable fit?
A: As long as your cable's outer diameter is between 8 mm and 12 mm, the standard sealing ring will work.
Q: Can I test one before placing a big order?
A: Absolutely. We recommend getting a sample first. You can check the fit and the seal on your actual cable before committing to a full run.
Get in Touch with Cablein Technology
Cablein Technology has been making waterproof connectors for industrial and outdoor use for years. We keep standard versions in stock and can customize pin layouts for your specs. If you need the LP20 7-Pin Plastic Metal Waterproof Crimp Plug for your next project, email us at nick@cableinco.com with your cable diameter and quantity.
