M16 Bulkhead Waterproof Connector
2. Delivers IP67 and IP68 waterproof sealing for enclosure pass-through applications.
3. Threaded rear body with solder cup or PCB pin termination options.
4. Ideal for medical devices, marine electronics, and industrial control cabinets.
5. Standard cutout size reduces panel preparation time and tooling costs.
6. CE and RoHS certified, manufactured under ISO9001 quality control.
7. Tested for 500+ mating cycles to ensure dependable performance.
8. Custom pin length, mounting thread length, and internal wire leads available.
M16 Bulkhead Waterproof Connector – Enterprise-Grade Panel-Mount Solution
Cablein Technology's M16 Bulkhead Waterproof Connector delivers enterprise-level sealing performance with IP67/IP68 protection for critical panel-mount applications. Engineered from PA66 nylon with gold-plated brass contacts and precision silicone O-rings, this connector offers 2 to 12-pin configurations supporting up to 500V and 12A ratings. Tested for 500+ mating cycles and temperature ranges from -40℃ to 150℃, it features a 16mm standard cutout design that reduces installation time by 30%. Our threaded rear body accommodates both solder cup and PCB terminations, while the integrated panel seal prevents moisture ingress at mounting surfaces. CE and RoHS certified under ISO9001:2015 quality systems, this product provides <5mΩ contact resistance for reliable signal transmission in medical devices, marine electronics, and industrial control cabinets.
Why Choose Panel-Mount Waterproof Connectors?
Your hardware walled in areas confront consistent dangers from clean, dampness, and weight wash-downs.
Traditional cable organs and grommets regularly come up short at section focuses. They permit water drainage that harms delicate electronics.
Panel-mount circular connectors illuminate this powerlessness. They make airtight seals at the most basic junction—where cables pass through walled in area walls.
The M16 standard offers the culminate adjust. It's compact sufficient for swarmed control boards however vigorous sufficient for unforgiving mechanical environments.
You get quick-disconnect comfort without relinquishing natural assurance. Field upkeep gets to be speedier and safer.
Technical Specifications That Matter
Core Performance Parameters
Electrical Ratings:
- Voltage capacity: 500V / 100V / 60V (depending on pin count)
- Current handling: 12A / 8A+3A / 3A per contact
- Dielectric withstand: 3KV / 1KV
- Insulation resistance: ≥200MΩ
Environmental Protection:
- Ingress rating: IP67 certified (IP68 available)
- Operating temperature: -40℃ to 150℃
- Mating cycle life: 500+ operations
- Contact resistance: <5mΩ
Construction Details
Materials:
- Housing: PA66 nylon for chemical resistance
- Contacts: Gold-plated brass for corrosion protection
- Seals: Medical-grade silicone O-rings
- Panel gasket: Integrated waterproof flange
Mounting Options:
- Front-mount: External installation with internal securing
- Rear-mount: Inside installation with external securing
- Standard 16mm cutout diameter
- Threaded locking nut included
Pin Configurations Available
You can select from multiple contact arrangements:
- Standard: 2, 3, 4, 5, 6, 8, 10, 12 pins
- Hybrid: 2+3, 2+4, 3+3 power/signal combinations
This flexibility lets you match exact circuit requirements without oversizing your connector.
Real-World Applications
Industrial Automation
Your PLC cabinets and sensor networks need connections that survive daily high-pressure wash-downs. Panel-mount connectors eliminate the weak points where cables enter control boxes.
Renewable Energy Systems
Solar inverters and battery storage units operate 24/7 outdoors. The bulkhead design withstands UV exposure and temperature swings while maintaining seal integrity.
Marine Electronics
From navigation systems to underwater robotics, the 16mm bulkhead provides structural strength against hydrostatic pressure. EMI shielding protects sensitive signal transmission in electrically noisy environments.
Medical Equipment
Diagnostic devices and monitoring systems require clean, reliable connections. Gold-plated contacts ensure stable signal transmission for sensitive data collection.
LED Lighting Infrastructure
Outdoor lighting systems in stadiums, landscape projects, and agricultural facilities face constant moisture exposure. Panel-mount connectors seal junction boxes at mounting surfaces.
Key Advantages for Your Application
Space-Efficient Design
The compact 16mm body fits crowded control panels. You maximize functional density without sacrificing connection quality.
Multiple Termination Styles
Choose solder cup or PCB pin terminations based on your internal circuit design. This flexibility simplifies integration with existing boards.
Superior Contact Performance
Gold-plated copper alloy contacts deliver low resistance for both power and signal applications. You get stable transmission even in sensitive circuits.
Installation Flexibility
Both flange and rear-mount variants accommodate different enclosure designs. Your installation team can select the best approach for each application.
Customization Options
We offer custom pin lengths, thread dimensions, and pre-wired internal leads. Your specific requirements don't force you into off-the-shelf compromises.
Proven Durability
500+ mating cycles mean your connections withstand repeated field maintenance. Reduced failure rates lower your total cost of ownership.
Quality You Can Verify
Every M16 Bulkhead Waterproof Connector undergoes comprehensive testing:
Environmental Sealing: 24-hour submersion tests at 1.5 meters verify IP67/IP68 ratings.
Corrosion Resistance: 48-96 hour salt spray testing (ASTM B117) confirms long-term performance in harsh conditions.
Electrical Safety: Dielectric withstand voltage testing prevents arcing between contacts.
Mechanical Reliability: Torque and pull-force testing ensures bulkhead nuts don't loosen under vibration.
Our ISO9001:2015 certified facility performs 100% inspection on waterproof performance, durability, and electrical reliability.
Manufacturing Capability Behind Your Order
Production Scale: Our 6,000㎡ office houses progressed fabricating gear worked by 200+ prepared professionals.
Inventory Solidness: We keep up 10,000+ pieces per standard thing. You dodge supply chain disruptions.
Delivery Speed: Standard orders transport inside 7-10 days. Custom ventures take after adaptable scheduling.
Global Coordinations: Associations with UPS, DHL, and FedEx empower effective around the world shipping.
Technical Bolster: 24-hour building help makes a difference you select the right setup and troubleshoot installation challenges.
Compliance and Certifications
Our products meet international standards:
- CE marking for European markets
- RoHS environmental compliance
- ETL, PSE, SAA for regional safety requirements
- TUV verification
- ISO9001:2015 quality management
These certifications simplify your procurement process and ensure regulatory compliance across global markets.
FAQ
Q: What's the contrast between front-mount and rear-mount configurations?
A: Front-mount connectors introduce from exterior the board and secure inside. This gives cleaner outside appearance. Rear-mount adaptations secure from exterior, letting you total inside wiring some time recently last assembly.
Q: Can this connector handle information transmission?
A: It's optimized for control and low-frequency signals. Protected variations back direct information rates. For high-speed applications like Cat6a, consider M12 X-coded alternatives.
Q: How do I keep up the IP68 rating amid installation?
A: Take after producer torque details for the bulkhead nut. Guarantee O-rings situate on level, clean surfaces without burrs. Any surface inconsistency compromises the seal.
Q: Ought to I select metal or plastic housing?
A: Metal lodgings give predominant EMI/RFI protecting and mechanical quality. PA66 plastic offers superior erosion resistance in acidic situations and costs less for weight-sensitive applications.
Q: How does warm extension influence sealing?
A: Quality connectors utilize silicone or EPDM gaskets that keep up flexibility over the full temperature extend. This anticipates seal disappointment amid fast warm cycling.
Q: What stick setup ought to I select?
A: Coordinate your circuit prerequisites precisely. Cross breed setups like 2+3 combine control and flag in one connector, diminishing board cutouts.
Q: Are custom determinations available?
A: Yes. We offer custom stick lengths, mounting string measurements, and pre-wired inside leads. Our building group underpins OEM/ODM ventures with private shape development.
Ready to Solve Your Panel-Mount Challenges?
Get the exact specifications you M16 Bulkhead Waterproof Connector need. Email nick@cableinco.com to request technical datasheets, discuss your specific configuration requirements, or arrange sample evaluation.
